ADLINK Hurricane-QM57 User Manual
Page 3
TME-EPIC-HURQM-R2V9 Revision
2.9
i
Table of Contents
1
Overview
1
1.1
Introduction .............................................................................................. 1
Features ................................................................................................... 1
Block Diagram ........................................................................................... 2
1.2
Ordering Information .................................................................................. 3
Hurricane-QM57 Models ............................................................................... 3
Cable Sets and Accessories ............................................................................ 4
1.3
Specifications ............................................................................................ 5
Electrical Specifications ................................................................................. 5
Environmental Specifications .......................................................................... 6
Mean Time Between Failures .......................................................................... 6
1.4
Mechanical ............................................................................................... 6
2
Getting Started
8
2.1
Connector Locations ................................................................................... 8
Top ......................................................................................................... 8
Bottom .................................................................................................... 9
2.2
Jumper Locations ....................................................................................... 10
2.3
LED indicators ........................................................................................... 11
2.4
Hardware Setup ......................................................................................... 13
3
Module Description 15
3.1
Processor ................................................................................................. 15
3.2
Platform Controller Hub (PCH) ..................................................................... 15
3.3
Graphics-Controller .................................................................................... 17
