TME-EPIC-HURQM-R2V9 Revision 2.9 Page 5 of 74
1.3
Specifications
Electrical Specifications
Supply voltages ATX power supply with 5V, 5V always, 3.3 volt. 12 volt DC
Rise time < 10 ms
Supply voltage tolerance ± 5% *
Inrush currents +5VSB: 1.0A
+5V:
0.5A
+3.3V: 0.2A
+12V: 2.5A
Supply current in S3-Mode
(Suspend-to-RAM)
+5VSB: 0.22A
Supply currents with
i7-620UE **
peak TDP idle
+5VSB 1.00 0.14 0.14
+5V 0.50 0.10 0.10
+3.3V 0.20 0.12 0.12
+12V 2.60 1.80 0.75
Supply currents with
i7-610E **
peak TDP idle
+5VSB 1.00 0.14 0.14
+5V 0.50 0.10 0.10
+3.3V 0.20 0.12 0.12
+12V 4.00 3.60 0.75
* With that tolerance it is not mentioned that all plugged devices are running with.
** That rate of current is possible when only monitor, mouse and keyboard are plugged.
The current increases if additional peripheral devices are connected.
