ADLINK aTCA-6250 User Manual

Page 28

Lower Non-Recoverable Threshold = 1.215 Volts

(25)

P1V8_LAN_82576

(0x18)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.98 Volts
Upper Critical Threshold = 1.944 Volts
Upper Non-Critical Threshold = 1.908 Volts
Lower Non-Critical Threshold = 1.692 Volts
Lower Critical Threshold = 1.656 Volts
Lower Non-Recoverable Threshold = 1.62 Volts

(26)

P1V8_LAN_I350 AM4

(0x19)

(27)

P1V_LAN_82576

(0x1A)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.1 Volts
Upper Critical Threshold = 1.08 Volts
Upper Non-Critical Threshold = 1.06 Volts
Lower Non-Critical Threshold = 0.94 Volts
Lower Critical Threshold = 0.92 Volts
Lower Non-Recoverable Threshold = 0.9 Volts

(28)

P1V_LAN_I350 AM4

(0x1B)

(29)

CPU1 Temp(PECI)

(0x1C)

CPU Temperature.
Upper Non-Recoverable Threshold = 95 degrees C
Upper Critical Threshold = 75 degrees C
Upper Non-Critical Threshold = 60 degrees C
Lower Non-Critical Threshold = 0 degrees C
Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C

(30)

CPU2 Temp(PECI)

(0x1D)

(31) System

PROG

(0x1E) System Firmware Progress Sensor.

(32)

48V_A Power(V)

(0x1F)

48V Voltage Sensor.
Upper Non-Recoverable Threshold = 55 Volts
Upper Critical Threshold = 50 Volts
Upper Non-Critical Threshold = 49 Volts
Lower Non-Critical Threshold = 36 Volts
Lower Critical Threshold = 35 Volts
Lower Non-Recoverable Threshold = 33 Volts

(33)

48V_B Power(V)

(0X20)

48V Voltage Sensor.
Upper Non-Recoverable Threshold = 55 Volts
Upper Critical Threshold = 50 Volts
Upper Non-Critical Threshold = 49 Volts
Lower Non-Critical Threshold = 36 Volts
