ADLINK aTCA-6250 User Manual

Page 27

Lower Critical Threshold = 0.69 Volts
Lower Non-Recoverable Threshold = 0.675 Volts

(17)

P_VCCP1

(0x10)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.385 Volts
Upper Critical Threshold = 1.365 Volts
Upper Non-Critical Threshold = 1.35 Volts
Lower Non-Critical Threshold = 0.6 Volts
Lower Critical Threshold = 0.58 Volts
Lower Non-Recoverable Threshold = 0.56 Volts

(18)

PVSA_CPU1

(0x11)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.232 Volts
Upper Critical Threshold = 1.215 Volts
Upper Non-Critical Threshold = 1.2 Volts
Lower Non-Critical Threshold = 0.6 Volts
Lower Critical Threshold = 0.582 Volts
Lower Non-Recoverable Threshold = 0.565 Volts

(19)

PVTT_CPU2

(0x12)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.137 Volts
Upper Critical Threshold = 1.117 Volts
Upper Non-Critical Threshold = 1.095 Volts
Lower Non-Critical Threshold = 1.005 Volts
Lower Critical Threshold = 0.984 Volts
Lower Non-Recoverable Threshold = 0.871 Volts

(20)

P0V75_DDR_VTT2

(0x13)

Voltage Sensor.
Upper Non-Recoverable Threshold = 0.825 Volts
Upper Critical Threshold = 0.81 Volts
Upper Non-Critical Threshold = 0.795 Volts
Lower Non-Critical Threshold = 0.705 Volts
Lower Critical Threshold = 0.69 Volts
Lower Non-Recoverable Threshold = 0.675 Volts

(21)

P_VCCP2

(0x14)

(22)

PVSA_CPU2

(0x15)

(23)

P1V1_SSB

(0x16)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.21 Volts
Upper Critical Threshold = 1.188 Volts
Upper Non-Critical Threshold = 1.166 Volts
Lower Non-Critical Threshold = 1.034 Volts
Lower Critical Threshold = 1.012 Volts
Lower Non-Recoverable Threshold = 0.99 Volts

(24)

P1V5_SSB

(0x17)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.65 Volts
Upper Critical Threshold = 1.62 Volts
Upper Non-Critical Threshold = 1.59 Volts
Lower Non-Critical Threshold = 1.296 Volts
Lower Critical Threshold = 1.242 Volts
