ADLINK aTCA-6250 User Manual

Page 26

Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C

(9)

LM73 TEMP CPU1_1

(0x8)

Temperature Sensor.
Upper Non-Recoverable Threshold = 95 degrees C
Upper Critical Threshold = 75 degrees C
Upper Non-Critical Threshold = 60 degrees C
Lower Non-Critical Threshold = 0 degrees C
Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C

(10)

LM73 TEMP CPU1_2

(0x9)

(11)

LM73 TEMP CPU1_3

(0xA)

(12)

LM73 TEMP CPU2_1

(0xB)

(13)

LM73 TEMP CPU2_2

(0xC)

Temperature Sensor.
Upper Non-Recoverable Threshold = 95 degrees C
Upper Critical Threshold = 75 degrees C
Upper Non-Critical Threshold = 60 degrees C
Lower Non-Critical Threshold = 0 degrees C
BIOS
Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C

(14)

LM73 TEMP CPU2_3

(0xD)

(15)

PVTT_CPU1

(0xE)

Voltage Sensor.
Upper Non-Recoverable Threshold = 1.137 Volts
Upper Critical Threshold = 1.117 Volts
Upper Non-Critical Threshold = 1.095 Volts
Lower Non-Critical Threshold = 1.005 Volts
Lower Critical Threshold = 0.984 Volts
Lower Non-Recoverable Threshold = 0.871 Volts

(16)

P0V75_DDR_VTT1

(0xF)

Voltage Sensor.
Upper Non-Recoverable Threshold = 0.825 Volts
Upper Critical Threshold = 0.81 Volts
Upper Non-Critical Threshold = 0.795 Volts
Lower Non-Critical Threshold = 0.705 Volts
