analog trigger source. The trigger level can be set by software
with 24-bit resolution, with characteristics as shown.
Table 3-4: Preferred Characteristics for Analog Triggers
Trigger Export
The PXIe-9529 can export trigger signals to PXI Trigger Bus
Numbers 0 through 7, utilizing them to act as the System Syn-
chronization Interface. When configured as the output, the
PXIe-9529 serves as a master module and can output trigger
signals to synchronize the slave modules, with the trigger sig-
nal routed to any of the seven PXI Trigger Bus Numbers via
software.
3.4 Trigger Mode
Two trigger modes applied to trigger sources initiate different data
acquisition timings when a trigger event occurs, as applied to
analog input and output functions.
Post Trigger Mode
If post trigger mode is configured, activity commences once the
following trigger conditions are met:
Z The analog input channel acquires a programmed num-
ber of samples at a specified sampling rate
Z
The analog output channel outputs pre-defined voltage
at a specified output rate
Trigger Level
Setting (Hex) Trigger Voltage
(-10V to +10V Range) Trigger Voltage
(-1V to +1V Range)
7FFFFF 9.99999881 V 0.999999881 V
7FFFFE 9.99999762 V 0.999999762 V
1 1.19 μV 0.119 μV
0 0V 0V
FFFFFF -1.19 μV -0.119 μV
800001 -9.99999881 V -0.999999881 V
800000 -10 V -1 V
