Introduction

3

PXIe-9529

Table 1-1: Channel Characteristics

SNR, @fin = 1kHz

103 dB

fs = 8.0 kS

104 dB

fs = 54.0 kS

99 dB

fs = 108 kS

98 dB

fs = 192 kS

THD

< -106 dB

SFDR

> 106 dB

crosstalk

< -100 dB

-3 dB bandwidth

>0.4863 fs

fs < 108 kS

≅ 0.2 fs

fs > 108 kS

IEPE

Current

4 mA, each channel independently
software configurable

Compliance

24V

Channel Characteristics

Comment
