6 Introduction
1.3.3 Triggers
Table 1-3: Trigger Source & Mode
Table 1-4: Digital Trigger Input
1.3.4 General Specifications
Trigger Source & Mode
Trigger source
Software, external digital trigger, analog trigger, PXI
trigger bus[0..7], PXI_STAR, and PXIe_DSTARB
Trigger mode Post trigger and delay trigger
Digital Trigger Input
Sources
Front panel SMA connector
Compatibility 3.3 V TTL, 5 V tolerant
Input high threshold 2.0 V
Input low threshold (VIL) 0.8 V
Maximum input overload -0.5 V to +5.5 V
Trigger polarity
Rising or falling edge
Pulse width 20 ns minimum
Physical
Physical dimensions 160 W x 100 H mm (6.24 x 3.9 in)
Bus
Bus interface PCI Express Gen 1 x 4
Environmental Tolerance
Operating
Temperature: 0°C - 55°C
Relative humidity: 10% - 90%, non-condensing
Storage
Temperature: -20°C - +80°C
Relative humidity: 10% - 90%, non-condensing
Calibration
Onboard reference
+5.000 V
