AR-V5430FL Installation Guide
4.5 Acrosser Wireless Networking WLAN (VNT6656G6A40)
Description
The Acrosser Networking WLAN embedded system/IA solution is the innovative design
of VNT’s wireless chipset. The WLAN module is fully compliant with IEEE’s security and
802.11g standards. Enabling data rates between wireless devices of up to 54Mbps, it
can deliver the bandwidth necessary for real-time streaming of high-definition digital
multimedia content in home networks, and provide high-speed email, Web and LAN
access to multiple mobile users in corporate environments or public hotspots.
Radio
Frequency Band
2400-2483.5MHz
Operating Channel
IEEE 802.1b, Direct Sequence
Spread Spectrum, IEEE 802.11g,
Orthogonal Frequency Division
Multiplexing 13 Channels
Modulation Type
QPSK, BPSK, CCK, OFDM
Data Rate
Up to 54Mbps
Antenna
To support two external antennas via
connector
Radiation Power
13-17dBm at maximum radiation direction
Voltage Supply
5V
Power Consumption
384 uA@5V, Suspend/high speed mode
259 mA@5V, Active/high speed mode
Receiver Sensitivity
Min -71dBm@54Mbps, PER<8%
Min -84dBm@11Mbps, PER<8%
Compliant
FCC Part 15 C
CE ETSI 300-328
USB-IF
