AR-V5430FL Installation Guide
CN3
SIM CARD SOCKET
PIN
SIGNAL
PIN SIGNAL
1
SIM_VCC
2
SIMRSCDn
3
SIMCKCDn
4
GND
5
X
6
SIMIOCDn
CON1
GSM/GPRS MODULE BOARD TO
BOARD CONNECTOR
PIN
SIGNAL PIN SIGNAL PIN SIGNAL PIN SIGNAL PIN SIGNAL
1
SIMCKCDn
11
X 21
GND
31
VDD_TOP
41
ON_KEY
2
SIM_VCC
12
X 22
GND
32 RI0 42
AUDIO_GND
3
SIMIOCDn
13 LPG_RED 23
GND 33 DTR0 43 MICP
4
SIMRSCDn
14
X 24
GND 34 CTS0 44 MICN
5 LPG_GREEN 15
TX0 25
GND
35 DSR0 45
X
6
GND 16
X 26
+4V
36 X 46 X
7
X
17
RX0 27
+4V 37 RTS0 47
X
8
X 18
X
28
+4V
38
X
48 X
9
X 19
X
29
+4V
39
DCD0
49
EARP
10
X 20
X
30
+4V
40
X
50
EARN
Features
Quad-Band GSM 850/900/1800/1900 MHz
GPRS Multi-Slot Class 10
Compliant to GSM phase 2/2+
Output power:
- Class 4 (2 W) for EGSM850
- Class 4 (2 W) for EGSM900
- Class 1 (1 W) for GSM1800
- Class 1 (1 W) for GSM1900
Control via AT commands
(Hayes 3GPP TS 27.007, TS 27.005)
TCP/IP stack access via AT commands
Internet Services: TCP, UDP
Supply voltage range: 3.4V~ 4.5 V
Power consumption
- Power down 60uA
- Sleep mode 3.0 mA
- Speech mode (average) 260 mA
- GPRS class 10 (average) 350 mA
29/39
Temperature range
- Normal Operation: -30°C to +85°C
