General, Accuracy, Datum – Acrosser AR-V5430FLAT User Manual
Page 31: Acc-v5430-gps (er-332-mcx90))
AR-V5430FL Installation Guide
4.3 ACC-V5430-GPS (ER-332-MCX90))
Features
SiRF StarⅢ high-performance GPS Chip Set
Very high sensitivity (Tracking Sensitivity: -159 dBm)
Extremely fast TTFF (Time To First Fix) at low signal level
Compact size (40.5mm * 35 mm * 10mm) suitable for space-sensitive application
Support NMEA 0183 and SiRF binary protocol
Build-in Super-Cap to reserve system data for rapid satellite acquisition.
Cold start under 40 seconds, average
Hot start under 1 seconds, average
Specification
General
Chipset
SiRF StarⅢ
Frequency
L1, 1575.42 MHz
C/A code
1.023 MHz chip rate
Channels
20 channel all-in-view tracking
Sensitivity -159
dBm
Accuracy
Position
10 meters, 2D RMS
5 meters, 2D RMS, WAAS enabled
Velocity 0.1
m/s
Time
1us synchronized to GPS time
Datum
Default WGS-84
31/39
