AR-V5430FL Installation Guide
not go to high) within 3 minutes after “OFF” pulse is sent, the AR-PW0932V will
send the off pulse to the motherboard again. If the motherboard still cannot be
shut down normally, the power output will be turned off directly.
F. If the ignition turns back to “ON” during the “OFF” Delay, the AR-PW0932V will
stay in operation. The “OFF” signal will not be sent to the motherboard. The
“OFF” Delay will re-start the next time when the ignition is off.
G. Power input monitoring: The AR-PW0932V will constantly monitor the input
voltage. If the input voltage is below 11.2 Volts (the standard might have 5%
tolerance), the AR-PW0932V will not start the power on procedure. When
AR-PW0932V has ran into operation and the battery drops below 10.8 Volts
(with 5% tolerance) for more than 10 seconds, the AR-PW0932V will shut down
the motherboard following the standard shut down procedure. If the input voltage
recovers within 10 seconds to a level of more than
10.8 Volts (with 5% tolerance)
again, the AR-PW0932V will continue to run. (Figure 4) If this happens, the
ignition shall be off and on again (Mode 2, 3, 4) or press the remote switch (Mode
5,6,7) if you want to turn on the system again.
LED flashing
A. Mode 0 and 1: The LED will be constantly ON when the power output is ON. The
LED will be constantly OFF when the power output is off.
B. Mode 2 to 7 (Smart ATX mode):
The LED will flash a number of times to indicate the status. Each blink remains 500
milliseconds ON followed by a 500 ms OFF. Each Cycle will have a 5-second OFF in
between.
26/39
LED flashing number
Status
0 (constant ON)
Power Output runs normally
1
Hard off mode
2
Standby mode (After power output is turned
off until 5VSB is turned off)
3
Power soft off delay. (After the ignition is
turned off or the remote switch is pressed
until power output is turned off.)
4
Battery voltage low
5
System on/off fail. When the motherboard
cannot turn on or turn off after retry.
6-128 Reserved
