Acrosser AR-B1894 User Manual

Page 14

IDE1 active LED (1-3)

System power on LED (2-4)

System reset LED (5-7)

System power on switch LED (6-8)

PCI1

PCI slot

PWR1

24-pin ATX power connector

SATA1, SATA2 Serial ATA 1 & 2 connector

SPK1

Internal speaker connector

1 x 4 header

SYS_FAN1

System fan connector

USB1LAN1

USB 1, 2 & LAN 1 connectors

USB2, USB3

Internal USB 3, 4 & 5, 6 connectors

2 x 5 header

VGA_COM1

D-sub 15-pin VGA & D-sub 9-pin serial
port 1 connectors
