LCP-1250RJ3SR-S
DELTA ELECTRONICS, INC.
4 Oct. 17. 2007 Rev. 1.02
www.deltaww.com
Pin Function Definitions
Pin Num. Name Function Plug Seq. Notes
1 VeeT Transmitter Ground 1 Note 5
2 TX Fault Transmitter Fault Indication 3 Note 1 - Function not available
3 TX Disable Transmitter Disable 3
Note 2 - Module disables on high or
open
4 MOD-DEF2 Module Definition 2 3 Note 3 - Two-wire serial ID interface
5 MOD-DEF1 Module Definition 1 3 Note 3 - Two-wire serial ID interface
6 MOD-DEF0 Module Definition 0 3 Note 3 - grounded in module
7 Rate Select Not Connect 3 Function not available
8 LOS Loss of Signal 3 Note 4 - Function not available
9 VeeR Receiver Ground 1 Note 5
10 VeeR Receiver Ground 1 Note 5
11 VeeR Receiver Ground 1 Note 5
12 RD- Inverse Received Data Out 3 Note 6
13 RD+ Received Data Out 3 Note 6
14 VeeR Receiver Ground 1 Note 5
15 VccR Receiver Power 2 Note 7 - 3.3V ± 5%
16 VccT Transmitter Power 2 Note 7 - 3.3V ± 5%
17 VeeT Transmitter Ground 1 Note 5
18 TD+ Transmitter Data In 3 Note 8
19 TD- Inverse Transmitter Data In 3 Note 8
20 VeeT Transmitter Ground 1 Note 5
Plug Seq.: Pin engagement sequence during hot plugging.
