66 Dynamic Pictures Oxygen 3D Family
Appendix E: Appendix E: Mechanical and Electrical Mechanical and Electrical
Specifications Specifications
Mechanical
The Oxygen 102 graphics accelerator card is a mechanically compliant
PCI option card in the PCI short-card form factor of 6.875 inches by 4.2
inches by 0.57 inches.
The Oxygen 202 graphics accelerator card is a mechanically compliant
PCI option card in the PCI form factor of 9.25 inches by 4.2 inches by
0.57 inches.
The Oxygen 402 graphics accelerator card is a PCI option card in the
PCI form factor of 12.28 inches by 4.2 inches by 0.59 inches.
Electrical
The Oxygen 102 card has a maximum power consumption of 10.5
watts, the Oxygen 202 card has a maximum power consumption of 24.7
watts, and the Oxygen 402 card has a maximum power consumption of
35.4 watts. The following table lists the measured current draw at all
supply voltages.
Maximum PCI Maximum PCI Power Consumption Power Consumption
Supply (Volts) Consumption (Amps)
Oxygen 102 Oxygen 202 Oxygen 402
+5 +/- 5% 2.0 4.7 6.7
+3.3 +/- 5% 0 0 0
+12 +/- 5% 0 0 0
-12 +/- 5% 0 0 0
