Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature T
S
-40 85 ºC
Supply Voltage V
CC
0 5 V
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Case Operating Temperature T
C
-5 70 ºC 1
Supply Voltage V
CC
3.135 3.465 V
Electrical Characteristics
(V
CC
=3.135V to 3.465V)
Parameter Symbol Min. Typ. Max. Unit Note
Total Supply Current I
CC
180 300 mA
Transmitter
Transmitter Differential Input Voltage
Vin,pp 0.5 2.4 V 2
Transmitter Disable Input-High V
DISH
2 V
CC
+0.3 V
Transmitter Disable Input-Low V
DISL
0 0.8 V
Transmitter Fault Pull up Resistor R
TX_FAULT
4.7 10 kΩ 3
Transmitter Fault Output-High V
TXFH
2 V
CC
+0.3 V
Transmitter Fault Output-Low V
TXFL
0 0.8 V
Receiver
Receiver Differential Output Voltage
V
out,pp
0.3 1 V 4
Receiver LOS Load R
RXLOS
4.7 10 kΩ 3
LOS Output Voltage-Low V
LOSH
2 V
CC
+0.3 V
LOS Output Voltage-High V
LOSL
0 0.8 V
Output Data Rise/Fall Time t
r
/ t
f
120 psec 5
Notes:
1. See Ordering information for detail
2. Internally AC coupled and terminated to 100 Ohm differential load.
3. Pull up to V
CC
on host Board.
4. Internally AC coupled, but requires a 100 Ohm differential termination at or internal to Serializer/ Deserializer.
5. Unfiltered, 20 – 80%.
