QR404 User Manual
35
Chapter 7: Specifications
Model Number QR404
Video System NTSC or PAL (Optional)
Video Compression Format H.264
Audio Compression Format 8kHz*16bit ADPCM
Video Input/Output 4-CH BNC Input / 2-CH BNC Output/ 1 VGA Output
Audio I/O 4-CH RCA Audio Input / 2-CH RCA Audio Output
Display Resolution D1:704×576(PAL) 704×480 (NTSC)
Frame Rate Single CH PAL: 25 fps NTSC: 30 fps
Recording Resolution
PAL: (CIF:352x288) | (HD1:704x288) | (D1:704x 576)
NSTC: (CIF:352x240) | (HD1:704x240) | (D1:704x 480)
Recording Frame Rate (Shared)
PAL: (CIF:100fps) | (HD1:50fps) | (D1:25fps)
NSTC: (CIF:120fps) | (HD1:60fps) | (D1:30fps)
Hard Drive 1 SATA HDD, up to 1TB；USB removable HDD (Backup)
Video Mode Always/Schedule/Manual/Motion Detection/Sensor Triggered
Record Pack Time 15/30/45/60 Min. Adjustable
Video Backup USB Flash Drive, Removable HDD, USB Burner, Network Backup to AVI File Format
Playback Mode PLAY /SLOW /FWD/Frame by Frame
Alarm Input/Output 4-CH Input / 1-CH Output
Alarm Type Motion/Sensor Triggered/Video loss/HDD Space/HDD Loss
PTZ Control Built-in RS-485 port, supports PELCO-P & PELCO-D
USB 2.0 Port
Supports USB Mouse, Removable HDD, USB Flash Drive to Backup to AVI File and Upgrade
System
Ethernet One RJ-45 10M/100M Self-Adaptable Ethernet Interface
Network Protocol Supports TCP/IP, DHCP, UDP, DDNS, PPPOE Network Protocol
Network Function
Supports Mobile Phone Surveillance, Real-Time Live Monitoring via IE-Based Browser and/or
Network and Remotely Setting DVR Parameters
Power Consumption 10-15 W
Power Adapter DC 12V;3A
Working Temperature 50°F to 104°F (10
℃ to 40℃)
Working Humidity 10%~90%
Dimension (W x D x H) 11.25 x 8.75 x 2.25 in (299 Ч 223 Ч 57 mm)
