MY& LEF-C Series
PanTilt VIDEO MONITOR
Model:
MYH-CUB
INSTALLATION & OPERATION MANUAL
SYSTEM OUTLINE & COMPONENTS ---------------------------------
MYH-CUB is a semi-flush PanTilt video monitor for use with LEF-5C and LEF-10C Master Sentry system. MYH-
CUB monitor, in conjunction with MYW-P1L or P3L, provides video for 1 to 3 entries for door answering and
surveillance.
MY-DC/A
MYW-P1L
Via MYW-BA
★ Refer to Installation & Operation Manuals packed with
MYW-P3L,
MYW-BA & BG-10C
for complete diagrams.
Components available
Package Contents
PanTilt video monitor (MYH-CUB)
Packet of screws
Installation & Operation Manual
PanTilt door stations • PanTiit door adaptor • MASTER SENTRY & Monitor • Power suppiy
Other models available:
• PanTilt door stations: MY-DG/A. Prism MY-EA, MY-FA. Wide-angle MY-DS. Overhead MY-CA (in MYW-CA).
• All Call, music & chime: either BG-10C or BGR-10A with AM/FM tuner. BG-10C requires PS-12F power supply,
12V DC, 2.5A. BGR-10A requires PS-24C.
• MYW-BA Long-distance adaptor can be added for an entry that is farther than 100m (330’) and up to 300m (980’).
