2-WIRED VIDEO ENTRY SECURITY SYSTEM

Model;

MY-DA

(Video doorstation, surface-mount)

J

INSTRUCTIONS

NAMES AND FUNCTIONS

©-

MOUNTING ACCESSORIES.

SCREW (x 2)

(for mounting to

single-gang box)

WOOD SCREW (x 2)

(for mounting to

pillar or wall)

SCREWDRIVER

(for tamper-proof

screw)

SPACER & SCREW

(for inclining the unit

to upward direction)

MY-DA

(J) CCD camera

Infrared LEDs

(J) Locator LED

¡3) speaker

(D Mic.

(D CALL button

(J)

Tamper-proof screw

a

FEATURES

*MY-DA is a video door station for use with MY-IAD room station with video monitor.

* Surface mounts to a single-gang box or on the wall directly.

* Simple 2-conductor wiring system.

* Employs CCD (Charge-Coupled Device) camera and infared LEDs.

* Weather-re sistant.

*Unit can be installed 6 degrees to adjust the camera viewing angle.
