ELECTRIC FIREPLACE
INSTALLATION INSTRUCTIONS
Models: (V)E32L, (V)E32LB, (V)E32LH, (V)E32LBH
(V)E36L, (V)E36LB, (V)E36LH and (V)E36LBH
PARTS LIST
This list contains replacement parts used in your fireplace. When ordering parts,
follow the instructions listed under Replacement Parts on page 15 of this manual.
PART NUMBER
KEY
NO. * E36LB
** E36LBH * E32LB
** E32LBH * VE36LB
** VE36LBH * VE32LB
** VE32LBH
DESCRIPTION QTY.
1 111065-02 111065-04 111065-02 111065-04 Louver Assembly (Bottom) 1
2 11198 11198 11198 11198 Screw #8x3/8 Hex 4
3 111065-01 111065-03 111065-01 111065-03 Louver Assembly (Top) 1
4 110870-01 110870-01 110870-01 110870-01 Bracket Refractory 2
5 106704-04 108401-03 106704-04 108401-03 Face Weldment 1
6 11166 11166 11166 11166 Screw #10 x 1/2 Hex 16
7 11164 11164 11164 11164 Screw #8 x 1/2 Phillips 22
8 112078-01 112078-02 112078-01 112078-02 Hearth Pan 1
9 112076-01 112076-02 112076-01 112076-02 Lower Face Rail 1
10 20088 20088 20088 20088 Door Stop 1
11 11318 11318 11318 11318 Rivet Pop 1/8 x .375 Black 2
12 112138-01 112138-02 112138-01 112138-02 Bracket Hearth Pan (B models only) 2
13 112288-01 112288-02 112288-01 112288-02 Imager Fireplace Insert 1
14 112137-01 113662-01 112137-02 113662-02 Refractory Panel (B models only) 2
15 112414-01 112414-02 112414-01 112414-02 Face Extension 2
16 110445-01 110445-01 110445-01 110445-01 Bracket Hearth 6
17 11105 11105 11105 11105 Screw #10 x 1/2 Hex 34
18 110973-01 110973-01 110973-01 110973-01 Cover Junction Box 2
19 14123 14123 14123 14123 Bushing Strain Relief Universal 1
20 112075-01 112075-01 112075-01 112075-01 Retainer Refractory 2
21 110794-01 110794-01 110794-01 110794-01 Junction Box 1
22 11102 11102 11102 11102 Screw #8-32 x 3/8 Phillips 6
23 M11143-1 M11143-1 M11143-1 M11143-1 Bushing Strain Relief 1
24 110446-02 108405-02 110446-02 108405-02 Firebox Wrap 1
25 111064-01 111064-01 111064-01 111064-01 Bracket Heater Standoff 2
26 110439-01 110439-02 110439-01 110439-02 Mount Heater 1
27 ** 111060-01 ** 111060-01 ** 111060-01 ** 111060-01 Heater Assembly **(H models only) 1
28 11404 11404 11404 11404 Wire Tie Down 1
29 107941-03 108408-02 107941-03 108408-02 Top/Bottom Firebox 2
30 112302-01 112302-04 112302-01 112302-04 Control Panel Assembly **(H models only) 1
30 112302-02 112302-05 112302-02 112302-05 Control Panel Assembly *(Non- H models) 1
31 112783-01 112783-01 112783-01 112783-01 Bracket Magnet 2
32 17223 17223 17223 17223 Magnet Catch 2
33 112099-01 112099-01 112099-01 112099-01 Deflector Heat Shield 1
34 11439 11439 11439 11439 Bushing Electric 7/8” 2
35 111134-01 111134-01 111134-01 111134-01 Label Wiring Diagram 1
36 112305-01 112305-01 112305-01 112305-01 Control Cover 1
37 11418 11418 11418 11418 Nut Push On 2
38 106691-01 108701-01 106691-01 108701-01 Screen Rod 2
39 12105 108440-01 12105 108440-01 Screen Assembly 2
40 112748-01 112748-01 112748-01 112748-01 Logs, Ember Bed 1
41 112735-01 112735-01 112735-01 112735-01 Grate Front 1
42 112743-01 112743-02 112743-01 112743-02 Panel Viewing Screen 1
* 43 25487 25487 25487 25487 Lava Rock 2.5# Bag 1
* Items not shown
21
