BEFORE ASKING FOR REPAIRS
Trouble Potential cause of trouble Solution
□ The system does not have chime tone
when caii button is pressed.
□ Cannot communicate with door station.
□ image does not appear when the
monitor button is pressed.
[Check the power suppiy. □Turn on the Power switch.
S
n
9
B/lake sure the system is being powered correctiy. [Check the power suppiy voitage.
□Check the wiring between the door station and
master station.
[Check if the cabie is connected to the
right terminais. (A1 to A1, A2 to A2)
□Hard to hear the caii tone from door
station.
□n some cases, environmentai noise around the
master station make the chime hard to hear.
Adjust tone voiume.
□Can hear outside voice even though
handset is not iifted.
[It is a normai operation. The system has a feature
to monitor outside instantiy when the caii is
pressed.
□Adjust monitor voiume. Add chime
extension speaker (iER-2) if
necessary.
□The LCD monitor iooks too dark or too
bright.
□ it is normai operation because of characteristics of
LCD panei.
[Adjust Bright controi.
□ Hard to see the monitor when it gets
dark outside.
□ White iight sometimes turns on at the
door station.
□ Appropriate iighting conditions are needed for a
ciear picture.
□ LED iiiuminators turn on automaticaiiy when it
gets dark outside.
[Adjust the White Light iiiuminator to □OFF
or ON as needed.
□"here is a white dot or a portion steadiiy
iit on the monitor.
at must be noted in advance that the TFT Color LCD panei, though manufactured with very
high precision techniques, inevitabiy has a very smaii portion of picture eiements that are
either steadiiy iit or not iit at aii, which is not considered a unit maifunction.
—/ specifications
KC-1GRD/1HRD (Main/Sub monitor station) KC-DAR (Video door station)
Power source DC24V Power
source DC12V in standby. DC22V in operation
(supplied from KC-1GRD)
Current
KC-1GRD Max. 700mA, 70mA standby
KC-1HRD Max. 500mA, 50mA standby
Current 4mA approx, in standby, 350mA approx, max.
Call tone
From video door station 4-Tone chime Call-in LED blinks
Master stations------► Sub master station
□ Electronic pre-tone and voice from the other station.
All call button blinks.
Picture element 1/4" color CCD
viewing
area
Appox. 2' Horiz., 3'8"~7'9" Vert.
at 4'3" high (up to box center) and 20" away from camera.
(60cm H, 111 ~235cm V at 130cm high &. 50cm away)
Wiring
Distance
KC-1GRD to the farthest KC1HRD i n
i 18AWG 330, 1.0 mm 100m
KC-1GRDto ER-2 Chime extension cn
22AWG 165, 0.65mm 50m
KC-DAR to KC-1 GRD L
Lighting
at night White LED illuminators cast up to T (30cm), in front of camera
□/Background scene beyond cannot be seen.
Communication Hands free
Communication Simultaneous via handset
Ambient
temperature
14°F~140°F(10°C~60°C)
Video monitor 4" TFT color LCD
Housing Fire-retardant ABS plastic.
Ambient temperature 32°F-104°F (0°-40°C)
Color Gray
Housing Fire-retardant ABS plastic Dimensions (H X W X D) 5-1/2" X 4-1/8" x 1-3/4", 140mm x 105mm x 44mrr
Color White Weight 0.68 lbs. (310g) approx.
Dimensions (H X W X D) 7-3/4" X 7-1/4" x 3-1/2", 195mm x 185mm x 88mm
Weight 2.2lbs.(1kg) approx.
Door release AC12V, 400mA
