Aiphone KC-1GRD - Manual

83058600 1099®
® AlPHONE'
VIDEO SENTRY COLOR TILT
AUDIO VIDEO ENTRY SECURITY INTERCOM
M odO lS!
KC“1GRD,
Main monitor station
KC“1 HRDj
Sub monitor station
INSTALLATIO N M ANUAL
o For installation of the KC-1SD and PS-24E, please refer to the respective Installation Manual for details.
Check the package contents before installation.
KC-DAR
f Package Contents n
Screws (2)
Wood Screws (2)
Hexagonal wrench j
Please save Hexagonal wrench for
maintenance.
KC-1GRD
CD CD □
0o|
Ì V. J
C Package Contents - n
Installation Manual
Operation
Manual
Screws (4)
Wood Screws (4)
Connector (for door release)
J
A PRECAUTIONS ON INSTALLATION & WIRING
This manual and the markings on the product contain various symbols In order that the product will be used safely and properly, and that the Installer
and user are protected from Injury and property damage. The following precautions must be thoroughly read and understood before proceeding.
^WARNING Negligence could result in death or serious injury.
CAUTION Negligence could result in injury or damage to property.
Explanation^f Symbols;
GENERAL
PRECAUTIONS
The A mark Indicates caution
statement (Incl. danger and
warning), which Is specifically
shown Inside.
o
GENERAL
INSTRUCTIONS
The O mark indicates contents
which demand a specific action
shown Inside or attached.
0
0
GENERAL
PROHIBITIONS
DISMANTLING
PROHIBITIONS MOISTURE
PROHIBITIONS
The 0 mark indicates contents which prohibit a specific action
shown Inside or attached.
A WARNING
Inside the KC-1GRD/1HRD monitor station, high voltage Is present. Do not open KC-1GRD/1HRD case
Do not change or alter KC-1 GRD/1 HRD. It can cause fire or electric shock. ®
Keep KC-1 GRD/1 HRD away from water or any other liquid. Fire or electric shock could result.
Do not put any metal through openings of KC-1 GRD/1 HRD. It can cause fire, electric shock or unit damage. ^
Keep AC cord of power supply from being marred or crushed. If damaged, fire or electric shock could result.
Do not plug or unplug with wet hands. Electric shock could result. G)
Keep AC plug away from moisture or dust. Fire could result. O
Do not use any power source other than specified. Fire or electric^ock could result. as electric shock could result. G)
G)
G)
9. Do not put any forcible strength on the video monitor. Damage may result
10. Make sure wires are connected properly before plugging in power supply.
A CAUTION
Do not install or make any wire terminations while power supply is plugged in. It can cause electrical shock or damage to the unit. O
Verify chime volume while handset is on the hook. Chime sound from KC-1 GRD/1 HRD speaker is loud, and may cause A
hearing damage. ^
Mount KC-1 GRD/1 HRD on wall in a convenient location, but not where it could be bumped or jarred.
In case of electrical storms, unplug power supply from AC outlet . It can cause fire, electric shock, or unit damage . Q
Do not install KC-1 GRD/1 HRD in any of the following locations, as it can cause fire, electric shock or unit damage:
G)
- High or extreme cold temperature area, under direct sunlight, near equipment that varies in temperature, in front of air conditioner,
inside a refrigerated area, etc.
- Places subject to moisture or humidity extremes (bathroom, cellar, greenhouse,etc.)
- Places subject to environmental conditions, such as oil, dust, chemicals, salt, etc.
- Places subject to constant vibration or impact.
- Where noise generating devices such as TV or radio are close by.
- Places subject to steam or smoke, (near heating equipment or cooking surfaces)
A GENERAL PRECAUTIONS
1. KC-1 GRD equipment, except for KC-DAR, is designed for indoor use only. Do not install outdoors.
2. KC-1 GRD system is not operational during a power failure.
3. In areas where broadcasting station antennas are close by, intercom system may be affected by radio frequency interference.
4. Keep all DC wiring at least 1', (30cm) away from AC 100-240V wiring, fluorescent lighting, or dimmer switches.
Otherwise, cross AC wiring at a 90° .
5. KC-1 GRD system must be installed at least 3'3", (1 m) away from TV or radio.
