FUNCTIONS
(1) IN USE -|
(2) NO SVC -
(3) ROAM —
(4) LOCK —_
(5) Power-------
Indicator
(6) Receiving
Signal
Strength
Indicator
(10) Send Key-I
(11) Power
On/Off Key
(12) One Touch -
Emergency
Key
p
(13) Digit -------1
Keys
I1B)N0 SVC ROAM LOCK
8888888888
Tull Bull IZI
Battery -------
Recharging
Jack
Microphone ■
j(i<£) (g) g)
©(g) g)
©©©
k© © ©
[Àmcwm ) I
Retractable
Whip Antenna
Earpiece
Earphone
Mic Jack
—(7) Digit
Display
p(8) Envelope
Message Icon
~-{9) Battery
Level
Indicator
(14) End Key
"T-ilSJ Multi
Function Key
sj :Recall/
Store key
(3 :Envelope
key
A :Up/Down
V Arrow Key
—(16) Clear Key
-(17) Function
Key
-(18) Voice Mail
Access/
Alpha Key
(I):MVX440
®:MVX470/
MVX475
( 1 )
( 2 )
(3)
(4)
(5)
INUSEi indicator lights when a call is in progress.
NOSVC (no service) indicator lights when the unit
is in a non-coverage area.
[ROAMi indicator lights when the unit is out of the
home area.
tOCKI indicator lights when the unit is locked.
( 6 )
(7)
(
8
)
(9)
(end key) terminates a call.
(C^ (Multi Function Key)
T is used as a POWER ON indicator which lights
when the unit is turned on.
RECEIVING SIGNAL STRENGTH INDICATOR:
The number of shaded blocks indicates the Receiv­
ing Signal Strength.
10-CHARACTER FUNCTIONAL DIGIT DISPLAY:
The remaining character show the last digits of the
dialed number.
3 Envelope Message Icon informs that there are
messages and/or calling line ID numbers in the
memory.
Biiil is used as a battery level indicator.
(10) CsE^(send key) is used for placing or receiving a call.
(11) @ (power on/off key) is used to turn on/off the unit.
(12) © One Touch Emergency key.
(13) DIGIT KEYS to enter a phone number.
(14)
(15)
a) ^^Recall/Store Key
• To recall phone numbers from repertory
memory, press
• To store phone numbers in repertory memo­
ry, press (^,
(^ (Envelope Key) is used for Voice Mail
l^ification and Caller ID.
o
or (Up-arrow Key or Down arrow Key)
• To control earpiece audio level, press A or V.
• To control alert tone level, press FNC A or V.
(16) @ (clear key) clears the digit(s) from the display.
@ (function key) shifts the digit keys to the func­
tional keys.
(voice mail access / alpha key)
• To access the linked speed dialing capability,
press (^.
• To enter alphabetical characters, oress
b)
c)
(17)
(18)
Earphone Mic Jack is used for handsfree operation with
EM-425 Earphone Mic (option).
