Specifications, Fm tuner, Am tuner – Clarion DRX9575Rz User Manual
Page 28: Cd player, Audio, General
32
DRX9575Rz
11. SPECIFICATIONS
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
11 dBf
50dB Quieting Sensitivity:
17 dBf
Alternate Channel Selectivity:
75 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (
±
3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25
µ
V
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (
±
1 dB):
5 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
100 dB
Dynamic Range (1 kHz):
95 dB
Harmonic Distortion:
0.01%
Notes:
• Specifications comply with EIA Standards.
• Specifications and design are subject to change without notice for further improvement.
Audio
Bass Control Action (30 Hz):
±
15 dB
Treble Control Action (10 kHz):
±
10 dB
Line Output Level (CD 1 kHz):
4 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Current Consumption:
Less than 7 A
Weight / Source unit:
4 lb. (1.8 kg)
Weight / Remote control unit:
1 oz. (30 g) (including battery)
Dimensions / Source unit:
7
" (Width)
×
2
" (Height)
×
6
-2/25" (Depth)
[178 (W)
×
50 (H)
×
152 (D) mm]
Dimensions / Remote control unit:
1-3/4
" (Width)
×
4-5/16
" (Height)
×
1
-1/8" (Depth)
[44 (W)
×
110 (H)
×
27 (D) mm]
