28
DRX9575Rz
Making fine adjustment of the
listening position
1. Upon completion of setting the listening
position, press ENT button ( .
2. Press the right or left side of SEARCH button
2 to select “RIGHT or LEFT” or “FRONT or
REAR”.
3. Tur n the Rotar y knob 3 clockwise or
counterclockwise to adjust the balance and
the fader.
4. Press ENT button ( to return to the DSP
mode.
Selecting a DSP menu
1. Press A-M button % to select “DSP”.
2. Press BAND button 4 to select “DSP Basic 1”
or “DSP Basic 2”.
3. Press one of Direct buttons $ and select the
desired a DSP menu.
∗
To select the user memory, press BAND button
4 to select “DSP User” and then press one of
Direct buttons $ .
Editing/storing a DSP menu (User
memory)
1. Select a DSP menu which you want to edit on
the basis of.
2. Press ADJ button & .
3. Press the right or left side of SEARCH button
2 to select the item to be adjusted.
There are EFFECT, DELAY, REAR MIX, REV.
TIME or ROOM SIZE and HIGH or LIVENESS
available for the items to be adjusted.
∗
For details on each adjustment item, refer to
the owner’s manual supplied with the
DPH7500z.
4. Tur n the Rotar y knob 3 clockwise or
counterclockwise to make the adjustment.
5. Repeat steps 3 to 4 to complete the
adjustment and press ADJ button & .
6. Press and hold one of the Direct buttons $
for 2 seconds or longer to store the edited
contents.
∗
You can give a title to the user memory. For
the inputting method of titles, refer to the
section “Entering titles” in “Operations
common to each mode”.
DSP Operations
∗
To select the user memory, press BAND but-
ton
4 to select “G.EQ User” and press one of
Direct buttons $ .
Editing/storing a G.EQ menu (User
memory)
1. Select a G.EQ menu which you want to edit
on the basis of.
2. Press ADJ button & .
3. Press the right or left side of SEARCH button
2 to select the frequency to be adjusted.
There are 50Hz, 100Hz, 200Hz, 400Hz, 1kHz,
3kHz and 12kHz available for the adjustment
frequency.
∗
For details on each adjustment item, refer to
the owner’s manual supplied with the
DPH7500z.
4. Tur n the Rotar y knob 3 clockwise or
counterclockwise to make the adjustment. The
adjustment range is from –12dB to +12dB.
5. Repeat steps 3 to 4 to complete the
adjustment and press ADJ button & .
6. Press and hold one of Direct buttons $ for 2
seconds or longer to store the edited contents.
∗
You can give a title to the user memory. For
the inputting method of titles, refer to the
section “Entering titles” in “Operations
common to each mode”.
Easy mode/DSP operations
DSP effect ON/OFF
∗
The factory default setting is “ON”.
1. Press A-M button % to select “DSP”.
2. Press S button # . When the “ON” is lit in the
display, the DSP effect is set to “ON”.
3. Press A-M button % .
Note:
• If the DSP effect is set to OFF, the adjustment
made in “DSP operations” is not reflected in the
music source.
Setting the listening position
1. Press A-M button % and select “DSP”.
2. Press the right or left side of SEARCH button
2 to set the listening position type.
There are FULL SEAT, FRONT-R (only right
seat), FRONT-L (only left seat), FRONT (only
front seats), REAR (only rear seats) and PASS
available for the listening position types.
∗
The factory default setting is “FULL SEAT”.
