Contents
Thank you for purchasing the Clarion DRX9575Rz.
∗
Please read this owner’s manual in its entirety before operating this equipment.
∗
After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗
Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗
This manual includes the operating procedures of the CD changer, MD changer, TV tuner and digital
sound processor (DSP) connected via the CeNET cable. The CD changer, MD changer, TV tuner and
DSP have their own manuals, but no explanations for operating them are described.
1. FEATURES
■
Rotary Encoder Volume Control with Multi-Color Prism Key
■
Touch-n-GO Motorized Sloping Console Detachable Face
■
High Visibility 8-Color Dot Matrix Large LC Display
■
RDS Reciever,
®
FM Reception System
■
Controller for Optional DSP/EQ, AMP. & TV Tuner Modules
■
Capability to Read CD TEXT Data from Clarion Compatible CD Changer
■
Z-Enhancer with 3 Adjustment Modes
■
CeNET with Balanced Audio Line Transmission and Dynamic Noise Canceling
■
8-Times Oversampling Digital Filter and Dual 1-Bit D/A Converters
■
Zero-Bit Detector™ Mute Circuit
■
4V/4-Channel RCA Line Level Output with Fader Control
■
4V/2-Channel Non-Fade RCA Line Level Output with Volume Control
■
1 Optical Digital Output
1.
FEATURES ..................................................................................................................................... 2
2.
PRECAUTIONS .............................................................................................................................. 3
Handling Compact Discs ................................................................................................................. 4
Sloping Console .............................................................................................................................. 4
3.
CONTROLS .................................................................................................................................... 5
4.
NOMENCLATURE .......................................................................................................................... 6
Names of Buttons ............................................................................................................................ 6
Display Items ................................................................................................................................... 6
LCD Screen ..................................................................................................................................... 6
5.
DCP ................................................................................................................................................. 7
6.
REMOTE CONTROL ...................................................................................................................... 8
Inserting the Batteries ..................................................................................................................... 8
Functions of Remote Control Unit Buttons ..................................................................................... 9
7.
OPERATIONS ............................................................................................................................... 10
Basic Operations ........................................................................................................................... 10
Radio Operations .......................................................................................................................... 13
RDS Operations ............................................................................................................................ 14
CD Operations ............................................................................................................................... 17
Other Handy Functions ................................................................................................................. 18
8.
OPERATION OF ACCESSORIES ................................................................................................ 21
CD Changer Operations ............................................................................................................... 21
MD Changer Operations ............................................................................................................... 23
TV Operations ............................................................................................................................... 25
DSP Operations ............................................................................................................................ 26
9.
TROUBLESHOOTING .................................................................................................................. 30
10. ERROR DISPLAYS ....................................................................................................................... 31
11. SPECIFICATIONS ........................................................................................................................ 32
