Foreword
This instruction Manual is the universal-purpose version for the models of separate wall-mounted
air conditioners manufactured by our Co.The appearance of the units that you purchase might be
slightly different from the ones described in the Manual, but it does not affect your proper
operations and usage.
Please read carefully the sections corresponding to the specific model you choose,and keep the
Manual properly so as to facilitate your reference at later time.
IMPORTANT!
Please Read Before Starting
This air conditioning system meets strict safety and operating standards.
As the installer or service person , it is an important part of your job to install or service the system
so it operates safely and efficiently.
For safe installation and trouble-free operation.you must:
• Carefully read this instruction booklet before beginning.
• Follow each installation or repair step exactly as shown.
• Observe all local,state,and national electrical codes.
• Pay close attention to all danger,warning,and caution notices given in this manual.
WARNINGiThis symbol refers to a hazard or unsafe practice which can result in severe personal
injury or death.
CAUTION:This symbol refers to a hazard or unsafe practice which can result in personal injury
and the potential for product or property damage.
CONTENTS
SELECTING THE MOUNTING POSITION
INSTALLATION DIAGRAM OF INDOOR UNITS
2
FRONT PANEL REMOVALAND INSTALLATION
LOCATION OF OUTDOOR UNIT
9
ELECTRICAL
CONNECTION
BETWEEN
OUTDOORAND
INDOORUNIT
10
INSTALLATION/SERVICE TOOLS (ONLY FOR R41OA PRODUCT
1
2
REFRIGERANTTUBING
14
THE INTRODUCTION OF THE ROTATIONAL ADAPTER:
15
AIRPURGING
16
SELF DIAGNOSIS FUNTIONS
18
WIRE DIAGRAM
19-21
