LAM-1 SYSTEM
LAM- 1
LA-A
)C-6\
•
PS-6D
Power supply
E0
+0
+0
——^ / ^Power supply is not required if master is
by batteries.
.
LA-AN
LA-D
m
H
L
|-"W|
H
p
1
LAM-3 SYSTEM
LAM-3
CALL BU7
LA-A:
1. Depress momentarily call button. You will hear a call tone. Wait for master to answer.
After master replies, communication from LA-A is hands free.
2. If no call tone is heard when LA-A call button is depressed, master is talking with other sub.
Please call later.
LA-D:
Same as LA-A.
CALL BUTTON
PRIV BUTTON
LA-AN:
Calling and talking operation same as LA-A.
LA-AN has privacy switch which allows a call to be received from master but prevents sound
going back to master. To place LA-AN in privacy position, depress PRIV button. To release
privacy switch for conversation, momentarily depress call button.
CALL BUTTON
-3
-
