Bolens 12203 - Manual (Page 7)

MODELS 12197 & 12203 BOLENS® 6HP TILLER
ENGINE, SUPPORT BRACKETS, PULLEYS, BELTS & BELT COVER
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY.
1 * * Engine-6HP, 21 1916728 Spring, Reverse Return............. 1
standard recoil start............... 1 22 1916522 Pulley, Transmission.................. 1
2 1916633001 Bracket, Clutch Cable............... 1 23 1440 Support Washer......................... 1
3 1100242 Lockwasher-5/16...................... 8 24 1916753 Reverse Drive Beit..................... 1
4 1111696 Screw-hex hd., 5/16-24 x 1/2.... 4 25 1909404 Forward Drive Belt..................... 1
5 1904557 Decal-Hot surfaces/belt warning. 1 26 1900396 Screw-hex hd., #10-32 x 1/2,
6 1917139 Cover-(incl. Ref. No. 5)............. 1 self-tapping............................. 4
7 1186391 Nut-5/16-18, Flange Lock......... 2 27 1916189001 Guard, Belts/Pulleys.................. 1
8 1108841 Key-3/16x 1-1/2......................... 2 28 1186230 Hex Nut, 5/16-18........................ 4
9 1138-1 Washer-Disc Spring.................. 1 29 1186329 Screw-flanged hex hd.,
10 1916520 Pulley, Engine Drive................. 1 5/16-18x3/4*............................ 4
11 9944 Washer, Belleville...................... 2 30 1916797001 Support Bracket-engine, left side. 1
12 9572 Screw-hex hd., 5/16-24 x 1 -1/8.. 2 31 1916796001 Support Bracket-engine, right side 1
13 1111606 Screw-hex hd., 5/16-18 x 2....... 1 32
....
Ref. No. not used.
14 1916578001 Reverse Idler Arm..................... 1 33
....
Ref. No. not used.
15 1916535 Pulley, Reverse Idler................. 1 34
....
Ref. No. not used.
16 1107382 Washer, Flat, 5/16..................... 2 35 1100799 Screw-hex hd., 5/16-18 x 1-1/2... 4
17 1916725 Belt Guide................................. . 1 36 1915810 Decal-Stabilization..................... 1
18 1110107 Locknut, 5/16-18....................... 1 37 1903584 Decal-Warning Hot Surface. (B).. 1
19 1916559001 Bracket, Reverse Idler.............. 1
20 1916536 Bushing..................................... 1
Specify GRADE 5 if ordering part locally.
* * See your local authorized engine service dealer for engine
parts or service. Refer to engine nameplate for engine type
and code information.
(A) Model 12197
(B) Model 12203
