MODELS 12197 & 12203 BOLENS® 6HP TILLER
HOOD, BRACKET & DEPTH REGULATOR
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY.
1 1917236 Hood-tine cover, with hinged fiap. 15 1186231 Nut-hex, 3/8-16.......................... 2
incl. Ref. No. 17, 20, 21. (B)... 1 16 20775 Drag Bar-depth regulator........... 1
1 1917239 Hood-tine cover, with hinged flap. 17 1916805 Decal-tiller operating instructions.
Incl. Ref. No. 21 - 27. (A) (B)........................................... 1
2 1100243 Lockwasher-3/8.......................... 2 18 9553 Screw-hex hd, self-tapping.
3 2527 Bracket-hood & depth regulator 5/16-18x1/2*............................ 2
(Incl. Ref. No. 9).................... 1 19 9552 Screw-flanged hex hd, self-tapping.
4 90038 Screw-flanged hex hd.. 1/4-20x1/2*............................. 2
5/16-18x5/8*........................... 2 20 1917199 Decal-Logo. (A and B)............... 1
5 9811 Locknut-hex, 1/4-20................... 1 21 1911361 Decal-Tine Warning. (B)............ 1
6 1100069 Screw-hex hd., 1/4-20 x 1 *....... 1 22 1916417 Decal-Read Operator Manual. (A)
7 9384 Spring-depth regulator plunger.... 1 [Not shown.]............................ 1
8 9438 Spacer........................................ 1 23 1916418 Decal-Thrown Object. (A)
9 9308 Roll Pin-1/4x 1 (spiral)............... 1 [Not shown.]............................ 1
10 1117A Bar Assembly-depth adjustment 24 1916419 Decal-Hot Surface. (A)
(Incl. Ref. No’s, 11 and 12)..... 1 [Not shown.]............................ 1
11 9120 Ring-retaining, toierance ring.... 1 25 1916420 Decal-Read Operator Manual before
12 9119 Knob-depth regulator Maintenance. (A) [Not Shown.] 1
(Incl. Ref. No. 11)................... 1 26 1916421 Decai-Belt. (A) [Not Shown.]...... 1
13 1100043 Screw-hex hd, 3/8-16 x 1-1/4*... 2 27 1916423 Decal-Tines. (A) [Not Shown.].... 1
14 1113-1 Bushing-spacer, drag bar.......... 2
Specify GRADE 5 if ordering part locally.
(A) Model 12197
(B) Model 12203
