MODELS 12197 & 12203

BOLENS® 6HP TILLER

TRANSMISSION HOUSING, COVERS, SEALS, GASKETS & PLUGS

REF
No.

PART

No.

DESCRIPTION

QTY.

REF
No.

PART

No.

DESCRIPTION

QTY.

1

9621

Oil Seal-double lip, wheel shaft,

13

1916273001 Cover-tiller housing, left side.....

1

right and left sides...................

2

14

1129-1

Gasket-tiller housing cover, .010

2

9726

Plug-pipe, 1/4, oil level hole and

(fits all covers).................

A/R

gear oil drain hole...................

2

15

1915089

Screw Kit: includes three (3)

3

97076

Seal-transmission bore..............

1

1/4-20

X

7/8 self-sealing ....

4

1186329

Screw-flanged hex hd.,

screws..............................

A/R

5/16-18x3/4*...........................

6

16

1115

Cap-rear bearing.......................

1

5

85030

Oil Seal-input pinion shaft..........

1

17

1124-2

Gasket-rear bearing cap, .010

6

11513

Cover-top of transmission (incl.

thick........................................ A/R

four of Ref. No. 18 and two of

18

1186331

Screw-flanged hex hd.,

each of Ref. No.’s 21 and 22).... 1

5/16-18x1*..............................

4

7

20694

Gasket-transmission top cover..

1

19

1915087

Screw Kit; includes five (5)

8

1916197001 Transmission case, tube and rear

1/4-20x5/8 self-sealing

housing assembly...................

1

screws.................................... A/R

9

9467

Plug-gear oil fill hole...................

1

20

This Ref. No. not used

10

1916198001 Plate-wheel drive cable mounting. 1

21

1100243

Lockwasher-3/8.........................

2

11

97073

Oil Seal-tiller shaft, left and right

22

1100068

Screw-hex hd., 3/8-16 x 3/4*.....

2

sides........................................

2

12

90038

Screw-flanged hex hd.,

5/16-18x5/8*............................

2

* Specify GRADE 5 if ordering part locally.

A/R-As Required
