MODELS 12197 & 12203 BOLENS® 6HP TILLER
HANDLEBAR ASSEMBLY & CONTROL LEVERS
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY
1 1917235 Handlebars-(incl. Ref. No.’s 2, 21 1114748 Screw-round hd, No. 10-32 x 1/2. 8
3 and 3A)............................... . 1 22 1100240 Lockwasher-No. 10.................... 4
2 9126 Grip-handlebars........................ . 2 23 1186208 Nut-hex, No. 10-32..................... 4
3 1917210 Decal-for operator control panel.. 1 24 9390 Grip-paddle................................. 2
3A 1917208 Decal- model name, logo......... . 1 25 20863 Bail-forward clutch control (incl.
4 1916784 Reverse Clutch Control Cable.. . 1 two Grips, Ref. No. 24)............ 1
5 20703 Handle, Height Adjustment....... . 1 26 20862 Adjuster Assembly (incl. Ref. No.’s
5A 9955 Washer-keyed........................... . 1 27, 28, 29, 30, 38 and 39)....... 1
6 1900475001 Bracket-handlebar height adjust.. 1 27 9532 Klip Ring..................................... 2
7 1100046 Screw-hex hd., 3/8-16 x 1 ....... . 2 28 20808 Adjuster, Right Side.................... 1
8 9904 Washer-plain (flat) 3/8, S.A.E... . 2 29 20809 Adjuster, Left Side...................... 1
9 9837 Locknut-hex, 3/8-16.................. . 2 30 9059 Spring-Adjuster........................... 1
10 9338 Hair Pin Cotter.......................... . 2 31 9522 Nut-rectangular........................... 1
11 1903597 Decal-forward clutch (A)........... . 2 32 9386 Klip Ring..................................... 1
13 9442 Wheel Gear Control & Cable 33 20831 Rod-forward clutch..................... 1
Assy. (incl. Ref. No.’s 14,15, 34 97083 Pin-Clevis................................... 1
19, 21,22, and 23)................. . 1 35 9853 Sems Nut.................................... 4
14 9057 Knob-wheel gear control lever..... 1 36 20806 Bracket-bail support................... 2
15 1186211 Nut-hex, 5/16-24, wheel gear 37 20888 Swivel......................................... 1
cable adjustment................... . 2 38 9432 Bushing....................................... 1
16 1100068 Screw-hex hd., 3/8-16 x 3/4*.... . 2 39 9973 Washer........................................ 1
17 1100243 Lockwasher-3/8........................ . 2 40 1100805 Screw-hex hd., 1/4-20 x 3/4*...... 1
18 1916900 Engine Throttle Control & Cable... 2 41 9811 Nut-1/4-20................................... 1
19 1735531 Ties-plastic................................ . 4 42 9552 Screw-flanged hex hd, self-
20 9212 Knob-throttle control lever........ . 1 tapping, 1/4-20 x 1/2*.............. 2
Specify GRADE 5 if ordering part locally.
(A) Model 12197
(B) Model 12203
