MODEL 12206
8HP MODEL TILLER
TINES, WHEELS
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
1
1100068
Screw-hex hd., 3/8-16 x 3/4*.... .. 12
9
1915056
Wheel & Tire Assy-left side.... ... 1
2
1985101
Tine-twin-edged, right facing...... 3
10
1915057
Wheel & Tire Assy-right side....... 1
3
1733398
Hex Locknut, 3/8-16................. .. 14
11
9380
Clevis Pin-.312
X1 -3/4 long... ... 2
5
1982612
Screw-hex hd., 3/8-16x2,
12
9338
Hitch Pin.................................. ... 2
GRADE 8............................... .. 2
7
1985100
Tine-twin-edged, left facing.... .. 3
8
1916693001 Tine Holder- left side............... ... 1
8A
1916694001 Tine Holder-right side.............. ... 1
IMPORTANT:
LEFT AND RIGHT SIDES OF TILLER ARE DETERMINED BY STANDING IN THE OPERATOR
POSITION (BEHIND THE HOOD) AND FACING THE DIRECTION OF FORWARD TRAVEL
MOUNT TINES SO THE CUTTING EDGE AT THE
TOP OF EACH TINE FACES THE OPERATOR
(TOP)
LEF-FACING TINE
■
I
5
RIGHT-FACING TINE
(BOnOM)
