MODEL 12206
8HP MODEL TILLER
REF
No.
PART
No.
DRIVE SHAFT
DESCRIPTION
QTY.
1
1714
Bearing-tapered roller with race.. 1
2
20718
Gear-spur, main drive shaft.....
1
3
9301
Key-3/16sq.x1.......................... 1
4
1916765
Drive Shaft-main drive shaft is one-
piece with integral, single-lead
work-hardened worm at front to
drive the wheel worm gear, and
integral six-lead work-hardened
worm at rear to drive the tiller
gear (also includes pressed-on
#1714 rear roller bearing, race
for bearing and #9301 key)...
1
REF
No.
PART
No.
DESCRIPTION
QTY.
5
1224-1
Shim-rear bearing cap, .010
As
thick (see Note 1 below)...Req’d
5
1224-2
Shim-same as above, but .030
As
thick (see Note 1).............. Req’d
5
1224-3
Shim-same as above, but .005
As
thick (see Note 1).............. Req’d
1325C Shim Set-includes the following
shims: two 1224-1; two 1224-2;
one 1224-3 .............................. As
Req’d
NOTE 1-Shim between drive shaft rear bearing and rear bearing cap to achieve 5-to-10 thousandths of an inch (.005-.010) end
play on drive shaft
INPUT PINION SHAFT & GEAR ASSEMBLIES
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
6
1100004
Screw-hex hd., 5/16-24 x 3/4*...
1
15
9677
Set Screw-5/16-18x3/8*...........
1
7
9944
Washer-disc spring (concave
16
20791
Input Pinion-steel shaft... ?....
1
surface faces pulley).............
1
17
20792
Gear-input pinion....................
1
8
9301
Key-3/16 sq. X1..........................
1
18
9093
Retainer-snap ring, external..
.. 1
9
20507
Pulley-transmission drive........
1
19
20799
Pinion Assy-(incl. one each of Ref.
10
1440
Washer-support.........................
2
No.’s 16,17 and 18...............
.. As
11
85030
Oil Seal-input pinion shaft, front.
1
Req’d
12
9500
Ring-retaining (snap ring), external 1
20
9517
Retainer-snap ring, internal..
1
13
9953
Washer-thrust............................
2
21
94018
Washer-sheave shoulder.......
1
14
9428
Bushing......................................
1
Specify GRADE 5 if ordering part locally.
