MODEL 12206
8HP MODEL TILLER
TRANSMISSION HOUSING, COVERS, SEALS, GASKETS AND PLUGS
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
1
9621
Oil Seal-double lip, wheel shaft,
13
1916199001 Cover-tiller housing, left side...
1
right and left sides..................
2
14
1129-1
Gasket-tiller housing cover, .010
2
9726
Plug-pipe, 1/4, oil level hole and
(fits all covers)........................ A/R
gear oil drain hole...................
2
15
1915089
Screw Kit: includes three (3)
3
97076
Seal-transmission bore..............
1
1/4-20 X 7/8“ self-sealing
4
1186329
Screw-flanged hex hd.,
screws..................................... A/R
5/16-18x3/4*.............................
6
161900881001
Cap-rear bearing........................
1
5
85030
Oil Seal-input pinion shaft.........
1
17
1124-2
Gasket-rear bearing cap, .010
6
1916193001 Cover-top of transmission.........
1
thick......................................... A/R
7
20694
Gasket-transmission top cover.
1
18
1186331
Screw-flanged hex hd.,
8
20893
Transmission case, tube and rear
5/16-18x1*................................
4
housing assembly...................
1
19
1915087
Screw Kit: includes five (5)
9
9467
Plug-gear oil fill hole..................
1
1/4''-20 X 5/8" self-sealing
10
1917101001 Plate-wheel drive cable mounting. 1
screws..................................... A/R
11
97073
Oil Seal-tiller shaft, left and right
20
This Ref. No. not used
sides.........................................
2
21
1100243
Lockwasher-3/8.........................
2
12
90038
Screw-flanged hex hd..
22
1100068
Screw-hex hd., 3/8-16 x 3/4*......
2
5/16-18x5/8*.............................
2
* Specify GRADE 5 if ordering part locally.
A/R-As Required
