MODEL 12206 8HP MODEL TILLER
HANDLEBAR ASSEMBLY AND CONTROL LEVERS
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY
1 1917240 Handlebars-(incl. Ref. No.’s 2, 3, 21 1114748 Screw-round hd, #10-32 x 1/2.... 8
3A and 4)................................... 1 22 1100240 Lockwasher, #10......................... 4
2 9126 Grip-handlebars.......................... 2 23 1186208 Nut-hex, #10-32........................... 4
3 1917217 Decal- operator control panel.... 1 24 9390 Grip-paddle.................................. 2
3A 1917215 Decal- Logo.................................. 1 25 20863 Bail-forward clutch control (incl.
4 9251 Grommet-plastic (part of operator two Grips, Ref. No. 24)............ 1
control panel)........................... 1 26 20862 Adjuster Assembly (incl. Ref. No.’s
5 1186347 Handle, height adjustment......... 1 27, 28,29, 30,38 and 39)........... 1
5A 9955 Washer-keyed.............................. 1 27 9532 Klip Ring...................................... 2
6 1900475001 Bracket-handlebar height adj..... 1 28 20808 Adjuster, Right Side.................... 1
7 1100046 Screw-hex hd., 3/8-16 x 1 *......... 2 29 20809 Adjuster, Left Side...................... 1
8 9904 Washer-plain (fiat) 3/8, S.A.E...... 2 30 9059 Spring-Adjuster........................... 1
9 9837 Locknut-hex, 3/8-16..................... 2 31 9522 Nut-rectangular........................... 1
10 9338 Hair Pin Cotter............................. 2 32 9386 Klip Ring...................................... 1
11 1916896 Reverse Clutch Lever- 33 20831 Rod-forward clutch..................... 1
complete (incl. grip, #9198).... 1 34 97083 Pin-Clevis..................................... 1
12 9198 Grip-reverse clutch lever............ 1 35 9853 Sems Nut..................................... 4
13 1916639 Wheel Gear Control & Cable 36 20806 Bracket-bail support................... 2
Assy.......................................... 1 37 20888 Swivel........................................... 1
14 9057 Knob-wheel gear control lever... 1 38 9432 Bushing........................................ 1
15 1186211 Nut-hex, 5/16-24, wheel gear 39 9973 Washer......................................... 1
cable adjustment..................... 2 40 1100805 Screw-hex hd., 1/4-20 x 3/4*....... 1
16 1100068 Screw-hex hd., 3/8-16 x 3/4*....... 2 41 9811 Nut-1/4-20..................................... 1
17 1100243 Lockwasher-3/8........................... 2 42 9552 Screw-flanged hex hd, self-
18 9445 Engine Throttle Control & Cable.... 2 tapping, 1/4-20 X 1/2*............... 2
19 9202 Ties-piastic................................... 4 43 20545 Washer- flat, 5/16"....................... 1
20 9212 Knob-throttle control lever......... 1 44 1185147 Pin - cotter................................... 1
