LAF-3A/A MASTER STATION OPERATION
* Placing a call;
1) If occupied lamp is not illuminated, depress a selector button of the desired
station. Then depress talk button to call by voice direct. To call by tone,
depress privacy and talk buttons simultaneously.
2) Depress talk button to talk, and release to listen.
3)
U p o n completing conversation, depress off button.
Calling
(1) Select (2) Depress both
(3)OFFi| call by tone.
NOTE: OFF button on LAF-3A/A master station, when depressed, puts station in standby mode as well as off
mode. OFF button MUST BE DEPRESSED AND LOCKED DOWN on all master stations except station
initiating a call or system will not work.
* Receiving a call from another master;
1) When your station is non-privacy position, no action is required and communication is hands free.
2) When your station is switched for privacy, release privacy switch by depressing talk button, then resume hands free
communication. Upon completing conversation, lock privacy switch or you can be monitered by other stations.
NOTE: There is no lamp annunciation between master stations except the occupied lamp.
Receiving a call from a sub station;
1) An incoming call is annunciated both by tone and lamp. Depress a
selector button above the lighted call lamp.
2) Use talk button to control communications. Upon completing conver­
sation depress off button.
Receiving a call from sub;
(1) Depress(2) Depress
<31 OFF I I j_ to talk
NOTE: When y o u receive calls f r o m another master and a sub at the s a m e t i m e r e p l y first to master and, after the
occupied lamp goes out, depress the selector button of the calling sub and communicate.
DO NOT DEPRESS THE SELECTOR BUTTON WHILE OCCUPIED LAMP ILLUMINATES.
CLEANING YOUR INTERCOM STATIONS
* Your Aiphone intercom .stations may be cleaned with a soft cloth dampened with household cleanser, such as Mr. Clean
or Fantastik.
* * *
We at AIPHONE are proud of our products. Our designers and engineers strive to bring you the finest in communication
equipment. Each item has been carefully tested and inspected before leaving our factory. Properly installed and used, your
Aiphone intercom system should give years of trouble-free service.
We are pleased to offer the following warranty:
Tirrmuir 111 xuii liÎtJÎÎÎMJ g
WARRANTY
Aiphone warrants its products to be free from defects of material and workmanship under normal
use and service for a period of one year after delivery to the ultimate user and will repair free of
charge or replace at no charge, should it become defective upon which examination shall disclose
to be defective and under warranty. Aiphone reserves unto itself the sole right to make the final
decision whether there is a defect in materials and/or workmanship; and whether or not the prod­
uct is within the warranty.
This warranty shall not apply to any Aiphone product which has been subject to misuse, neglect,
accident, or to use in violation of instructions furnished, nor extended to units which have been
repaired or altered outside of the factory.
This warranty does not cover batteries or damage caused by batteries used in connection with the
product.
This warranty covers bench repairs only, and any repairs must be made at the shop or place des­
ignated in writing by Aiphone. .Aiphone will not be responsible for any costs incurred involving on
site service calls.
Aiphone Co., Ltd., Nagoya, Japan
Aiphone Corporation, Bellevue, Washington
