Audiovox CTX-4200 - Manual (Page 5)

TELEPHONE UNIT
FUNCTIONS
Recei\'ing
Signal Strength
Indicator
(1) IN USE
(2) NO SVC
(2) ROAM
(4) LOCK
(5) Rower
Indicator
i;8) VAD
Registration Key
;i0) Power
On/Off Switch
¡11) Send Key
.13 Alpha Key
U) End Key
H) Function Key
IS) Recall Key
Ifi) Store Key
17) Clear Key
(21) SRFAKFK
(7) Alphanumeric
Dispaly
(9) One Touch
Dial Kevs
(M l. M-2)
(IS) \'olume Control
Keys
AUX I /0 JAC
Digit Keys
MIC. JACK
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
(
6
)
( 7 )
I IN USE I indicator lighits when a call is in prog­
ress.
( 8 )
( 9 )
(
10
)
(ID
(
12
)
(13)
( 14 )
( 17 )
( 19 )
I NO SVC I (no service) indicator lights when the
unit is in a non-coverage area.
I ROAM I indicator lights when the unit is out of
the home area.
I LOCK I indicator lights when the unit is locked.
pTÍ is used as a POWER ON isdicator which
lights when the unit is ON.
RECEIVING SIGNAL STRENGTH INDICA­
TOR ) The number of shaded blocks indicates
the Received Signal Strength.
15-CHARACTER FUNCTIONAL ALPHA
NUMERIC DISPLAY :
The first 5 characters indicate current function
and status conditions.
The remaining 10 characters show the last 10
digits of the dialed number.
ONE TOUCH DIAL KEYS permit you to place a
call by a single key stroke.
I POWER ¡ (Pewer on off switch) is used to turn the
unit on/off.
|SND| (send key) for placing or receiving a call.
IALPHI (alpha key) shift the digit keys to the
alphanumeric keys.
|END| (end key) terminates a call.
IFUNCI (function key) shift the digit keys to the
functional keys.
|RCL| (recall key) recalls phone numbers from
repertory memory,
ISTOj (store key) stores phone numbers in reper­
tory memory.
|CLR| (clear key) clears the digit(s) from the
display.
[V] , (volume control keys) control Loud­
speaker and Earpiece audio level as well as Alert
tone.
[V]: Lower , ) Louder
AUX I /10 JACK for Date Transmission.
DIGIT KEYS to enter a phone number.
Built in Loudspeaker
MICROPHONE JACK for HANDS FREE.
