Specifications AD-400
400 lbs. Metric Equivalents
182 kg
Total weight 9,800 lbs 4,454.5 kg
Total weight crated 10,100 lbs 4,590.9 kg
Tilt height 136.25" 346.08 cm
Operating height 114.25" 290.20 cm
Full tilt height 95" 241.30 cm
Operating depth 80.875" 205.42 cm
Width 123" 312.42 cm
Tilt load (rear tilt) 16 degrees 16 degrees
Tilt load (front load) 6 degrees 6 degrees
Unloading height from floor 43" 10922 cm
Loading height from floor 64" 16256 cm
Door opening 55"x49" 134.70 cm X 124.46 cm
Basket diameter 68.75" 174.63 cm
Basket depth 66.375" 16859 cm
Basket volume 143 cu ft. 4.03 cum
Minimum load size 200 lbs 90.72 kg
Maximum load size 400 lbs 181.44 kg
Gas burner type H i / L o Hi/Lo
Maximum heat input, gas dryers 1,600,000 btu/h 403,200 kcal/hr
Minimum heat input, gas dryers 40,000 btu/h 10,080 kcal/hr
Blower motor 25 hp 18.65 kw
Basket motors (2 motors) two 5 hp two 3.73 kw
Burner blower motors 3/4 hp .56 kw
Maximum airflow 9,C^cfm 255 cmm
Maximum exhaust duct back pressure 1.25" (wc) 3.1 mbar
Minimum exhaust duct diameter 20" 50.80 cm
Compressed air required 80 psi 5.63 kg/cm^
