B. INTERNAL F.T.FCTRTCAL CONDUTT. AIR AND WATER HOSE
RECONNECTIONS
Because the dryer is shipped in sections, wiring and hose connections must be reattached.
1. Air Hoses
These air hose reconnections must be completed:
a. Front Tilt Piston Lines
This reconnection is made at the front of the dryer in the space between the base and
lower bumer/heater section. Connect the red marked 3/8 poly flo tube into the red
marked brass elbow. Connect the black marked tube into the black marked brass elbow.
b. Rear Tilt Piston Lines
This reconnection is made at the rear of the dryer in the space between the base and
lower bumer/heater section. Connect the red marked 3/8 poly flo tube into the red
marked 3/8 poly flo tube union. Do the same for the black marked tube and union.
c. Sprinkler Valve Lines
The 1/4-inch aluminum tube reconnection is made at the rear of the dryer in the space
between the base and lower bumer/heater section. Connect the 1 /4-inch aluminum tube
into the 1/4-inch aluminum tube union.
d. Load Door Piston Lines
These reconnections are made inside the lower burner section. Open the lower
bumer/heater section access doors and reconnect the red marked 1/4-inch poly flo tubes
into the red-marked 1 /4-inch poly flo unions. Do the same with the black marked tubes.
2. Water Hose
a. Sprinkler water hose
If the tumbler section was shipped apart from the base module, reconnect the 1-inch
sprinkler water pipe union located on the left side of the base. This will reconnect the
1-inch mbber hose on the base into the mating 1-inch piping on the tumbler section.
3. Electrical Conduit Recormections
If the dryer was shipped in two (2) pieces, the following electrical conduits and plugs must be
reconnected.
