Generac IM-72LP Industrial Mobile Generator
REPAIR PARTS - V-TWIN ENGINE PARTS
DRAWING NO. 79216
ITEM PART NO. QTY. DESCRIPTION
ITEM DESCRIPTION
PART NO. QTY.
1
69331
1
CYLINDER ASSEMBLY
52
72347
2
SPARK PLUG-CHAMPION
2
69333
1
SLEEVE BEARING-30
DIA.
R12YC .
3
67805
1
OIL SEAL-30 DIAMETER
53
75258
1
GASKET KIT-ENGINE
4
79234
1
CYL. HEAD ASSEM.-NO. 1
54
75259
1
WASHER, BREATHER SCRW
5
79235
1
CYL. HEAD ASSEM.-NO. 2
55
75260
1
STARTER DRIVE ASSEMBLY
6
70169
4
SEALING WASHER
56
75261
1
CLUTCH ASSEMBLY
7
69332
2
GASKET-CYLINDER HEAD
57
66480
1
GASKET, AIR CLEANER
8
72301
1
BREATHER ASSEMBLY
58
75269
1
ARMATURE ASSEMBLY
9
72315
1
GASKET, BREATHER
59
72361
1
BUSHING, GOV. SHAFT
10
70190
1
SCREW, BREATHER
60
72362
1
BUSHING, GOV. SHAFT
11
70596
1
TUBE, BREATHER
61
70199
1
BAFFLE, BREATHER
12
69336
1
GASKET, OIL SUMP
62
72366
1
COTTER PIN
13
69325
8
BOLT, CYLINDER HEAD
63
72367
1
GOVERNOR FORK
14
67888
2
PLUG, OIL DRAIN-3/8”
NPT
64
72365
1
WASHER, GOV. SHAFT
15
72334
1
CRANK SHAFT ASSEMBLY
65
68555
2
DOWEL, CRANKCASE
16
75247
1
OIL SUMP ASSEMBLY
66
67806
4
DOWEL, CYLINDER HEAD
17
67924
1
OIL SEAL-35 DIAMETER
67
75262
1
SEAL, BREATHER SCREW
18
67878
9
BOLT, OIL SUMP
68
75263
1
SEAL, BREATHER SCREW
19
75248
2
PISTON ASSY-STANDARD
69
75264
1
STARTER GEAR
20
75249
2
RING SET- PISTON-
70
75265
1
STARTER END CAP ASSY.
STANDARD
71
75266
1
COMMUTATOR CAP ASSY.
21
69327
4
LOCKING RING, PISTON
72
75267
1
STARTER HOUSING ASSY.
22
75250
2
PISTON PIN-STANDARD
73
68572
2
SCREW, OIL PUMP
23
75251
2
CONNECTING ROD ASSY
74
75272
2
TERMINAL, SPARK PLUG
24
72346
4
BOLT, CONNECTING ROD
75
70122
2
SEAL, VALVE STEM
25
69316
2
EXHAUST VALVE
76
67910
2
SEAT, INTAKE VALVE
26
69317
2
INTAKE VALVE
77
67911
2
SEAT, EXHAUST VALVE
27
67816
4
VALVE SPRING
78
67813
4
VALVE, GUIDE
28
69320
4
RETAINER, VALVE SPRING
79
75268
1
RETAINER AND PIN
29
70513
4
KEEPER, VALVE
80
75270
1
ROLL PIN
30
70584
4
TAPPET, VALVE
81
70592
1
AIR CLEANER BASE
31
70530
1
CAMSHAFT ASSEMBLY
82
73123
1
AIR FILTER (FLAME
32
72358
1
INTAKE MANIFOLD
RETARDENT)
33
69379
2
GASKET, CARB. MNTG.
83
70593
1
COVER, AIR CLEANER
34
67895
2
GASKET, INTAKE MANIFOLD
84
72300
1
SCREW, AIR CLNR. COVER
35
70594
2
BOLT, CARBURETOR MNTG.
85
67156
2
SCREW, AIR CLEANER BASE
36
67158
4
BOLT, INTAKE MANFLD. MNT
86
69341
1
PRE-FILTER
37
68574
1
PIPE-PLUG, 1/8” NPT
87
80011
1
SPRING, BRUSH SET
38
68554
1
SEAL, GOVERNOR SHAFT
88
70597
1
TUBE, AIR INLET
39
68573
1
0-RING, OIL PUMP
89
69358
1
DEFLECTOR-BREATHER
40
70506
1
0-RING, OIL GALLEY
90
67920
2
GASKET, VALVE COVER
41
70554
1
SPACER, CARBURETOR
91
69328
1
ROCKER ARM COVER
42
70568
4
STUD, ROCKER ARM
92
70547
1
OIL PUMP ASSEMBLY
43
75253
4
SEAL, WASHER-VALVE CVR.
93
70536
1
GOVERNOR SLIDER
44
67885
4
NUT, NYLOK-M6
94
70577
4
PUSH ROD
45
75254
4
SCREW, VALVE ADJUST
95
70599
4
ROCKER ARM ASSEMBLY
46
70535
1
SCREEN, OIL
96
70567
2
SHAFT-ROCKER ARM
47
75255
1
STARTER MOTOR
97
70566
4
SUPPORT, ROCKER ARM
48
75256
2
BOLT, STARTER MOTOR
98
75271
1
KIT-VALVE OVERHAUL
49
75257
4
BRUSH ASSEMBLY
99
67897
2
GASKET, EXHAUST
50
67891
1
IGNITION ARMATURE ASSY.
100
91481
1
GASKET & CAP ASSEMBLY
51
72356
2
SCREW, IGNITION
ARMATURE
101
91480
1
ROCKER ARM COVER
