Generac IM-72LP Industriai Mobile Generator
REPAIR PARTS-SHEET METAL
DRAWING NO. 92935
ITEM
PART NO.
QTY.
DESCRIPTION
1
__
1
See Eng. Exp.View of Eng.
2
99258
1
Key, Woodruff-6
x
22mm
4
20102
1
Nut, Flange
5
87865
1
Plug, Flywheel Access
6
A4456
1
3/8" Special Lock Washer
7
86313
1
Housing, Engine Top
8
56893
23
Screw (Crimptite) -No. 10-24 x 1/2"
10
87750
1
Scroll, Flywheel
11
74916
1
Cover-Base #2
12
74908
9
Screw (Taptite)-MS x 10mm
13
73190
1
Wrapper-No. 2 Cylinder
14
78858
1
Cover,
Valley
15
78859
1
Wrapper-No. 1 Cylinder
16
74902
2
Wrapper - Barrel
17
66886
2
Capscrew, Hex Hd.-M6-1.00 x 12mm
19
73191
1
Cover, Base-No. 1 Cylinder
20
48571
2
Capscrew, Hex Hd. -M8-1.25 x 15mm
21
22129
2
Lockwasher - M8
22
75246
4
Screw (Taptite) 3/8"-16 x 1-1/4"
23
10-74260
1
Wire Assembly - No. 16
24
88290
1
Cover, Starter
25
73186
1
. Wrapper, Crankcase
26
81108
1
Bushing, Snap
27
22717-B
1
Grommet-Rubber
28
22717-A
2
Grommet-Rubber
29
67866
1
O-Ring
30
77001
1
Plug, Oil Fill
31
73132
2
Boot, Spark Plug
33
87858A
1
Ground Wire Assy. - Cyl. #2
34
29289
2 ft.
Foam Tape
35
87858B
1
Ground Wire Assy. - Cyl. #1
36
50277
1
Decal, Oil Drain
37
38153
2
No. 10-32
X
1-1/2" Screw
38
22152
2
No. 10 Lock Washer
39
33469
2
0.22 Inch I.D. Spacer
40
23897
2
No. 10 Flat Washer
41
92934
1
Regulator - 10A.
42
22158
2
No. 10-32 Hex Nut
