Generac IM-72LP Industrial Mobile Generator
EXPLODED VIEW - CARBURETOR
DRAWING NO. A4029
ITEM
PART NO.
QTY.
DESCRIPTION
1
A1662A
1
GARB. V-TWIN L/P
2
57822
2
HOSE CLAMP
3
74994
1
1/2”I.D. x I O ” LONG HOSE
4
26307
4
STREET ELBOWS
5
26915
1
3/4” PIPE NIPPLE
6
75211
1
GASEOUS FUEL REG.
7
A2666
1
GASEOUS FUEL SOLENOID
8
78864
1
REG. MNT. BRACKET
9
49813
4
M6
HEX NUT
10
22097
4
M6 LOCK WASHER
11
47411
2
M6-1.00X 16MM HEX HD.
CAPSCR.
12
38750
2
M6-1.00
X
30MM HEX HD.
CAPSCR.
13
37398
1
HEX LOCK NUT (NYLON)
14
74961
1
GOV. ADJUSTER BRACKET
15
56893
5
NO. 10-24
X
1/2” SCREW
16
47227
1
GOV. ADJUSTER SCREW
17
74962-C
1
GOVERNOR SPRING
18
66476
2
M6-1.0
X
12MM HEX SCREW
W/LOCKWASHER
19
81378-B
1
AIR CLNR. DECAL-IM-72-LPG
91351
1
AIR CLNR DECAL-NP-66-LPG
91352
1
AIR CLEANER DECAL-Q-55
91352-A
1
AIR CLEANER DECAL-Q-70
20
75944
1
GOV. SPRING BRACKET
21
73130
1
FLYWHEEL ASSEMBLY
22
70155
1
: GOVERNOR LEVER
23
76242
2
1/8” I.D.
X
1/8”
RIVET
24
70125
1
ANTI-LASH SPRING
25
70108
1
GOV.-TO-CARB. ROD
+
28739
4
4
”
LONG TIE
WRAP
+
55162
9cc
PIPE SEALANT
27
70103
1
AIR CLEANER SUPPORT
BRACKET
28
61696
+ NOT SHOWN
1
BARBED 90 DEG. 3/8” x 1/2”
