Generac IM-72LP Industrial Mobile Generator
REPAIR PARTS-BASE & PULLEYS
DRAWING NO. 92936
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 86318 1 BASE, MOUNTING 38 48031-E 2 CLAMP, HOSE-3/8”
2 68527 4 HHCS-M6-1.0 X 20 LONG 41 81105 2 5/16-18 FLANGE NUT, SPECIAL
3 46911 4 MOUNT, (RUBBER) 43 75710 1 TUBE, OIL FILL AND DRAIN
4 25017 8 CAPSCREW, HEX HD.- 44 74958 1 CAP & DIPSTICK ASSEMBLY
3/8--6 X 1/2" 45 67871 1 O-RING, CAP
5 22237 12 LOCKWASHER-M10 46 A5508 1 OIL FILL TUBE GASKET
6 22129 2 LOCKWASHER-M8 47 75711 1 PIPE, OIL DRAIN ADAPTOR
7 72391 2 SKID, RUBBER MOUNT 48 22413 1 CAPSCR., HEX HD.-
9 22259 2 NUT, HEX-5/16-18 1/4-20x1” LONG
10 52858 6 NUT, FLANGED LOCK- 49 A5802 1 TINNERMAN CLIP
M8-1.25 50 43790 1 ELBOW-3/8” NPT X 3/8”
11 51730 2 CAPSCR. HEX HD.- 51 47290 1 HOSE-3/8" I.D. #6202A
M8-1.25X60MM 52 35461 1 FITTING, BARBED-1/4” NPT
12 29459 2 SPRING, BELT TENSION 53 69811 1 CAP, HEX-1/4” NPT
13 75215 2 WASHER, SPRING CNTR. 54 65852 1 CLIP, HOSE RETAINER
14 73146 4 SLIDE (NYLON) 56 73179 1 OIL FILTER SUPPORT
15 75209 2 SUPPORT, NYLON SLIDE 57 70185 1 FILTER, OIL (FRAM#PH3614)
16 73174 1 MANIFOLD, EXHAUST 58 60108 1 10 PSI-SWITCH, OIL PRESS.
17 79678 2 GASKET, EXH. MANIFOLD 59 74948 3 FITTING-5/16”
18 55173 4 CAPSCR., HEX HD.- 60 74950 1 TUBE, OUTER OIL
M8-1.25X20MM 61 74951 1 TUBE, INNER OIL
(GRADE 10.9) 62 73134 1 ADAPTOR, OIL PAD
19 72383 2 GASKET, COLLECTOR PAN 63 38750 3 CAPSCREW, HEX HEAD-
21 75224-E 1 PULLEY, ENGINE-5.2 M6-1.00x30MM
75224-B 1 PULLEY, ENGINE-5.5 64 74949 1 FITTING, 90-DEGREE-5/16”
75224-F 1 PULLEY, ENGINE-6.6 65 68548 1 GASKET, OIL PAD
75224-G 1 PULLEY, ENGINE-7.2 66 62684 1 LUG, GROUNDING
22 73106-E 1 PULLEY, ALT.-5.2 67 29289
_
TAPE, FOAM-1/16” THICK x 8 ’
73106-B 1 PULLEY, ALT.-5.5 69 75281 1 SWITCH, HIGH TEMP.
73106-F 1 PULLEY, ALT-6.6 70 74027 2 SCREW, PAN HEAD M3-0.50
73106-G 1 PULLEY, ALT.-7.2 71 43182 2 LOCKWASHER-M3
23 75216 1 BELT (POLY V 4L)-40” 73 75237 4 WASHER, SPRING RETAINER
24 49451 1 WASHER, PULLEY RETAINER 74 77681 1 CAP, VINYL-LOS-2 WIRE
25 42633 1 CAPSCR., SOCKET HD. 3/8”- 75 75474 1 CAP, VINYL-17Dx42Lx2H
4 X 1” (GRADE 5) 76 90800
1
ELBOW, EXH. -UNIVERSAL
26 77017 1 GUIDE, BLOWER H O U S IN G 77 94670 1 CLAMP, EXHAUST-1-1/8”
27 73118 1 CAPSCR., HEX HD.- 78 75226 1 COVER, AIR
3/8”-24 X 2-1/2” 79 56893 23 SCREW (CRIMPTITE)-
28 74906 10 SCREW (TAPTITE)-M6-1.00x20 NO. 10-24 X 1/2” LONG
29 74908 1 SCREW (TAPTITE)-M5-0.80x10 80 75229 1 GASKET, SLIDE PAN
30 72375 1 HOUSING, BLOWER 81 75227-A 1 SLIDE PAN
31 73185 1 SPACER, BLOWER HOUSING 82 68527 4 CAPSCREW, HEX HEAD-
32 22097 6 LOCKWASHER-M6 M6-1.00 X20MM WITH
33 77682 1 CAPSCR. HEX HD.- LOCK WASHER
M5-0.80 X 80MM 83 22473 5 FLATWASHER-M6
34 75242 4 SPRING, GEN. SET MT 84 22097 4 LOCKWASHER-M6
35 49813 2 NUT, HEX M6X1.0 85 72384-C
1 COVER, EXH. OUTLET
36 45757 2 CAPSCREW, HEX HEAD- 87 77643 1 GASKET, EXH. OUTLET
M6-1.0X25 LONG 90 22447 1 LOCK WASHER-M6,
37 90859 1 COVER PLATE TOOTHED
