Generac IM-72LP Industrial Mobile Generator
REPAIR PARTS - CONTROL PANEL
DRAWING NO. 92856
ITEM
PART NO. QTY.
DESCRIPTION
ITEM
PART NO. QTY.
DESCRIPTION
1
75995
1
LOWER BEARING CARRIER
36
82737
4
VIBRATION MOUNT
2
80095G
1
ROTOR ASSEM.
37
49813
4
M6-1.0HEXNUT
3
92848
1
STATOR ASSEM.
38
49815
1
M5-08X16LG. HEX HD.
4
73159
1
BALL BEARING
CAPSCR.
5
31971
1
BALL BEARING
39
43182
2
M3-LOCK WASHER
6
72379
1
UPPER BEARING CARRIER
41
53623
1
C/BREAKER 2.5A.
7
77006
4
STUD-STATOR
42
67444
2
M5 SHAKEPROOF WASHER
8
52858
8
M8-1.25 FLANGE LOCK NUT
43
83049
1
REGULATOR VOLTAGE
9
66386
1
BRUSH HOLDER
44
49226
6
M5-LOCK WASHER
10
66849
2
M5-0.8X16LG. TAPTITE
45
51716
4
M5-0.8 HEX NUT
11
27756
4
NYLON WASHER
47
82081
1
C/BREAKER 30A.
12
86314
1
GEN. TOP HOUSING
48
25105
4
#6-32 W/LOCK WASHER
14
22473
2
M6-FLAT WASHER
SCREW
15
22097
4
M6-LOCK WASHER
49
86315
1
PANEL COVER
17
90141
2
GROUND CABLE
50
90734
4
M4-0.7X 16 LG. CAPSCR.
18
22447
1
SHAKEPROOF LOCK
W/LOCK-WASHER &
WASHER
FLAT WASHER
19
74906
4
M6-1.0X20 LG. TAPTITE
51
22985
3
M4 FLAT WASHER
20
92234
1
CONTROLLER P.C.B.
52
32300
1
FUSE HOLDER
21
10-74260 1
STARTER CABLE
53
22676
1
FUSE AGC-15A.
22
22129
2
5/16 LOCK WASHER
54
87798
1
SWITCH S.P.D.T. 6A-
23
22259
2
5/16-18 HEX NUT
(START-STOP).
24
86316
1
PANEL SHEET METAL
55
92113
1
SWITCH S.P.S.T.-
25
53650
1
4-PIN CONNECTOR
(FUEL PUMP)
26
20757
1
CONNECTOR
56
75210-A
1
TERMINAL BLOCK
27
75244
1
REMOTE HARNESS
57
23365
1
M4 SHAKEPROOF
WASHER
28
66886
2
M6-1.0
X
12MM CAPSCREW
58
51715
1
M4-0.7 HEX NUT
29
86729
1
STARTER CONTACTOR
59
90157
1
DECAL, CB RATING
30A.
30
75476
4
M4-0.7
X
16 LG. CAPSCREW
62
31791
1
CLAMP, CABLE
31
22264
4
M4 LOCK WASHER
63
23897
1
M5 FLAT WASHER
32
38077
1
CIRCUIT BREAKER 15A.
64
74908
1
M5x 10 LONG TAPTITE
33
90987
2
M3-0.5
X
15 LG. CAPSCREW
65
23484-S
1
BUSHING
34
86317
1
PANEL SUPPORT BRACKET
66
75763A
1
BOOT, BATTERY CABLE
35
75235
4
M5-0.8
X
30 LG. CAPSCREW
