SmartSwitch Router User Reference Manual 85
Chapter 6: BGP Configuration Guide
Figure 4 illustrates a sample IBGP Internal group configuration.
Figure 4. Sample IBGP Configuration (Internal Group Type)
The CLI configuration for router SSR1 is as follows:
AS-1
SSR2 SSR1
17.122.128.2/24 17.122.128.1/24
16.122.128.1/24 16.122.128.1/24
16.122.128.8/24 16.122.128.9/24
C2 C1
Physical Link
Legend:
Peering Relationship
ip-router global set autonomous-system 1
bgp create peer-group int-ibgp-1 type internal autonomous-system 1
bgp add peer-host 16.122.128.2 group int-ibgp-1
bgp add peer-host 16.122.128.8 group int-ibgp-1
bgp add peer-host 16.122.128.9 group int-ibgp-1
