Generac NP-66LPG Recreational Vehicle Generator
APPLYING LOADS TO GENERATOR
When applying electrical loads to the generator, observe these
guidelines;
• Before applying electrical loads, let the generator stabilize
and warm up for a minute or two.
• DO NOT overload the generator.
■ LETTING THE ENGINE STABILIZE
The generator supplies correct rated frequency and voltage
only at the proper governed speed. Some electrical appli
ances may be extremely sensitive to voltage and frequency.
Incorrect frequencies and/or voltages can damage those appli
ances.
If electrical loads are applied at reduced operating speeds, such
loads imposed on the engine when sufficient power is not avail
able may shorten engine life. Never turn ON electrical loads
until after the generator engine has started and stabilized
ON-speed.
■ DO NOT OVERLOAD THE GENERATOR
You can read the rated wattage/amperage capacity of your
generator on the generator data plate (see “Identification
Record” on Page 1).
/^plying electrical loads in excess of the unit’s rated capac
ity will cause the engine-generator to automatically shutdown.
To avoid overloading, add up the wattage of all connected elec
trical lighting, appliance, tool and motor loads. This total should
not be greater than the generator’s rated wattage capacity.
• Most lighting, appliance, tool and motor loads indicate their
requir^ watts on their nameplate or data plate. For light
bulbs, simply note the wattage rating of the bulb.
• If a load does not show its rated wattage, multiply that load’s
rated VOLTS times AMPS to obtain WATTS.
• Induction type motors (such as those that run the vehicle’s
furnace fan, refrigerator, air conditioner, etc.) need about 2-
1/2 times more watts of power for starting than for running
(for a few seconds during motor starting). Be sure to allow
for this when connecting electrical loads to the generator.
Rrst, figure the watts needed to start electric motors in the
system. To that figure, add the running wattages of other
items that will be operated by the generator.
• Do not apply heavy electrical loads for the first two or three
hours of operation.
WATTAGE REFERENCE GUIDE
RUNNING
WATTS
*Air Conditioner (12.000
Btu)..................................................1700
Battery Charger (20 amp)....................................................................... 500
Belt Sander (3")...................................................................................... 1000
Chain Saw......................................... ..................................................... 1200
Circular Saw (6-12")...............................................................800 to 1000
Coffee Maker..........................................................................................1000
•Compressor (1 HP)...............................................................................2000
•Deep Freeze............................................................................................ 500
Disc Sander (9")......................................................................................1200
Electric Range (one element)............................................................... 1500
Electric Skillet........................................................................................ 1250
•Furnace Fan (1/3 HP).......................................................................... 1200
Hair Dryer............................................................................................ 1200
Hand Drill (1")......................................................................................... 1100
Hedge Trimmer........................................................................................450
Impact Wrench..:...................................................................................... 500
RUNNING
WATTS
Lawn Mower...........................................................................................1200
Light Bulb...................................................................................................100
Microwave Oven..................................................................................... 700
•Milk Cooler............................................................................................ 1100
Oil Burner on Furnace..............................................................................300
Oil Fired Space Heater (140,000 Btu).....................................................400
•Paint Sprayer, Airless (1/3 HP)...............................................................600
Radio.............................................................................................50 to 200
•Refrigerator.........................................................................................v. 600
Slow Cooker................... ......................................................................... 200
•Submersible Pump (1-1/2 HP)......................................................... ..2800
•Submersible Pump (1 HP)......;........................ .2000
Table Savy (10”).................................................................. 1750 to 2000
Television........................................................ .................... 1750 to 2000
• Allow 2-1/2 times the listed watts for starting these
devices.
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
