O j , GeneracNP-66LPG Recreational Vehicle Generator
-------------------------------------------------
Drawing No. 79216
REPAIR PARTS LIST - 6N-480 ENGINE
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 69331 1 Cylinder Assembly 51 72536 2 Ignition Armature Screw
. 2 69333 1 Sleeve Bearing 52 72347 2 “D” Spark Plug
3 67805 1 Oil Seal 53 75258 1 Engine Gasket Kit
4 79234 1 No. 1 Cylinder Head Assembly 55 75260 1 Starter Drive Assembly
5 79235 1 No. 2 C^inder Head Assembly 56 75261 1 Clutch Assembly
6 70169 4 Sealing Washer 57 66480 1 Air Cleaner Gasket
7 69332 2 Cylinder Head Gasket 58 75269 1 Armature Assembly
8 72301 1 Breather Assembly 59 72361 1 Governor Shaft Bushing
9 72315 1 Breather Gasket 60 72362 1 Governor Shaft Bushing
10 70190 2 Breather Screw 61 70199 1 Breather Baffle
11 70596 1 Breather Tube 62 72366 1 Cotter Pin
12 69336 1 Oil Sump Gasket 63 72367 1 Governor Fork
13 69325 8 Cylinder Head Bolt 64 72365 1 Governor Shaft Washer
14 67888 2 3/8” NPT Oil Drain Plug 65 68555 2 Crankcase Dowel
15 72334 1 Crank Shaft Assembly 66 67806 4 Cylinder Head Dowel
16 75247 1 Oil Sump Assembly 67 75262 1 Breather Screw Seal
17 67924 1 Oil Seal Assembly 68 75263 1 Breather Seal Screw
18 67878 9 Oil Sump Bolt 69 75264 1 Starter Gear
19 75248 2 Standard Piston Assembly 70 75265 1 Starter End Cap Assembly
20 75249 2 Standard Piston Ring Set 71 75266 1 Commutator Cap Assembly
21 69327 4 Piston Locking Ring . 72 75267 1 Starter Housing Assembly
22 72520 2 Standard Piston Ring 73 68572 2 Oil Pump Screw
23 72521 2 Connecting Rod Assembly 74 75272 2 Spark Plug Terminal
24 72346 4 Connecting Rod Bolt 75 70122 2 Valve Stem Seal
25 69316 2 Exhaust Valve 76 67910 2 Intake Valve Seat
26 69317 2 Intake Valve 77 67911 2 Exhaust Valve Seat
27 67816 4 Valve Spring 78 67813 4 Valve Guide
28 ■ 69320 4 Valve Spring Retainer 79 75268 1 Retainer and Pin
29 70513 4 Valve Keeper 80 75270 1 Roll Pin
30 70584 4 Valve Tappet 81 70592 1 Air Cleaner Base
31 70530 . 1 Camshaft Assembly 82 73123 1 Air RIter
32 72358 1 Intake Manifold 83 70593 1 Air Cleaner Cover
33 69379 2 Carburetor Mounting Gasket 84 72300 1 Wr Cleaner Cover Screw
34 67895 2 Intake Manifold Gasket 85 67156 2 Air Cleaner Base Screw
35 70594 '2 Carburetor Mounting Bolt 86 69341 1 Foam Pre-cleaner
36 67158 4 Intake Manifold Mounting Bolt 87 80011 1 Brush Set Spring
37 68574 1 1/8” NPT Plug Pipe 88- 70597 1 Air Inlet Tube
38 68554 1 Governor Shaft Seal 89 69358 1 Breather Deflector
39 68573 1 Oil Pump 0-ring 90 67920 2 Valve Cover Gasket
40 70506 1 Oil Galley 0-ring 91 69328 2 Valve Cover
41 70554 1 Carburetor Spacer 92 70547 1 Oil Pump Assembly
42 70568 4 Rocker Arm Stud 93 70536 1 Governor Slider
43 75253 4 Washer Valve Cover Seal 94 70577 4 Push Rod
44 67885 4 , M6 Nylon Nut 95 70599 4 Rocker Arm Assembly
45 75254 4 Valve Adjust Screw 96 70567 2. Rocker Arm Shaft
46 70535 1 Oil Screen 97 70566 4 Rocker Arm Support
47 75255 1 Starter Motor 98 75271 1 Valve Overhaul Kit
48 75256 2 Starter Motor Bolt 99 . 67897 2 Exhaust Gasket
49 75257 4 Brush Assembly 100 91481 1 Gasket and Cap Assembly
50 67891 1 Ignition Armature Assembly 101 91480 1 Rocker Arm and Cover
