FUEL REQUIREMENTS
The “NP" series generator is equipped with a liquefied petro­
leum (LP) gas fuel system. LP gas is usually supplied as a
liquid in pressuré tanks.
“NP” series generators require a “vapor withdrawal” type fuel
system. This type of gaseous fuel system uses the vapors form­
ing above the liquid fuel in the storage tank. Air temperature
around the storage tank must be high enough to sustain ade­
quate fuel vaporization. In colder climates, you may need to
use an independent heat source to be sure the fuel suffi-
cently vaporizes in the storage tank.
LP gas may consist of propane, butane or mixture of two
gases. Propane vaporizes at temperatures as low as -20^
(-29®C), but butane returns to its liquid state when the tem-
perture drops below about 32°F (0“C). For that reason, a
higher ratio of propane is desired in the gas mixture when tem­
peratures drop below freezing.
ENGINE OIL REQUIREMENTS
Use a high quality detergent oil classified “For Service SP and
with an oil viscosity rating of SAE10W-30 oil. Do not pour in
any additives to the recommended oil. Engine crankcase
capacity is 1.5 U.S. quarts (1.4 liters). See MAINTENANCE
section for oil level check and filing procedures.
ENGINE SPECIFICATIONS
Type of Engine.......................................... ....................... Twin Cylinder
Cooling Method..................................................................... Air-cooled
Rated Horsepower...................................................... ,.16 at 3600 rpm
Displacement................................ .............................................. 479.4cc
Compression Ratio........................................................................ 8.6 to1
Cylinder Block........................................................ Aluminum with cast
iron sleeve
Type of Governor...................................................... Mechanical, fixed
speed
Engine Governed Speed............................................ See chart above
Air Cleaner.............................................................. Paper element with
foam pre-cleaner
Starter...................................................................... 12 volts DC electric
Ignition S^tem.............................. ................................ Solid state with
flywheel magneto
Recommended Spark Plugs
Champion.................................................................................RC12YC
AC............................................................ ■........... R45S
Fram Autolite.......................................................65
Spark Plug Gap......................................................................... 0.030 inch (0.8mm)
GENERATOR SPECIFICATIONS
Rotor RPM...................................................-........................... .........3600
Rotor Poles............................................................................... .'.............. 2
Engine RPM......................................................................................2700
Rated Maximum Continuous
AC Output................................................................6600 watts (6.6 kw)
Voltage.......................................................................................120 volts*
Rated Maximum Continuous AC Current.......................55 amperes
Phase................................................................................................single
Frequency....................................................................................60 Hertz
Weight.................................................................................. 213 pounds
Length...................................................................................................... 25 inches
Width.....................................................................................................18.5 inches
Height................................................................................................. 15.75 inches
* The unit is reconnectable to 120 and/or 240 volts, dual voltage
output.
Rated maximum continous current at 240 volts is 27.5 amps.
