When starting scarification, lower the support rollers to the
relevant working height. Usually position 3. (Ulus. 1)
Position 3 = Maximum cutting depth (10 mm)
Position 2 = Minimum cutting depth (3 mm)
Position 1 =Transport position
PRIOR TO START
I
• Before starting the machine ensure that the blades are
not damaged. Ensure that the bearing housing, which
isolates the blades, is not damaged.
« Before using the machine you should always check that
the blades and other underchassis parts are not worn or
damaged. Change all blades at the same time to ensure
. the rotating parts are balanced.
STARTING
To start the machine:
• Press down on the handle in order to lift the
front of the machine up thus keeping the blades clear of
the lawn. (Ulus. 3)
« Press in the locking button on the switch body (2 illus. 1)
and press the trigger against the handle (1 illus. 1)andthe
blade shaft will rotate.
• Release the locking button. ■
iMPOBtANt INFORMATION
the machine #iou)d hot ije Jeaned at an angle more '
' than thait required arid gply that part directed away :,
OPERATING
° Raise the handle until the support roller at the
■ front of the machine is in contact with the'
ground.
«. Walk forward slowly. Adjust walking speed to the lawn’s
condition. Slower walking speed results in a higher cutting
rate. If you run into stones or suchlike then press the handle
down to to lift the blades clear of the ground.
» Handle the electric cable as in ¡llus. 4.
WARNING! If an accident occurs feg: the
cable is pulled into the blade shaft then
release the switch trigger immediately:
pisGonneot the plug at the socket. Have the cable
repaired professionally or buy a new one. ,,,
STOPPING / TRANSPORTING
» Avoid frequent starting and stopping
° Release the switch trigger and disconnect the
machine from the socket if the machine is to be cleaned or
carried.
' ' . '
' o Always set theheight adjustment to transport position when
not in use.
« During transport the handle should be carefullyfolded up.
Ensure the cable is not damaged.
» Allow the motor to cool down before packing in a box or
crate.
MAINTENANCE OF
THE VERTICAL SCARIFIER
The blades must be kept sharp in
order to obtain good results. These
are wearing items and must there­
fore be checked and replaces when
IMPORTANT INFORMATION
• Check regularly that all nuts, screws, arid Beats aré
wefi tightenied arid teplace any damaged partá.
Only otigipal ipar# parts should be used.
• Cleaning, maintenance and.servioe may onlytíé'
done when the machiné is disconnected from №e
socket.
•, Do not wash the machine with water. ’
» Check the cables regularly for wear and ageing. ,;
• Never usetherriachine in rainyweatheror let St
standoutsideintheraln: • . . '
• • .Keep the motor free from grass, leaves and
. excess grease in order to rilintmiseflrB^risk. ' '
necessary. The electrical equipment on the machine, such
as the cable, the on / off switch etc. must be frequently
checked from a safety aspect. Any defects discovered
must be rectified before use.
« Clean with a brush after use. N.B.! Do not wash with
water.
o Check regularly that the blades have not loosened’.
AIR INLET FILTER
ÎMPÔRTÂNt INFORMATION
The ait in tet fiiter must be cleaned when required.
iOâè'a;‘8dft;bfu8bfû:rem6ve dry grass, leaves etc.
The filter may be taken out for cleaning with com­
pressed air.
STORAGE
Store the machine in a dry place. Prevent rusting by treating
all parts with a rustprevention agent.
